40 NetVista™ Technical Information Manual
A31 Address/data 18 I/O B31 +3.3 V dc
A32 Address/data 16 I/O B32 Address/data 17 I/O
A33 +3.3 V dc B33 C/BE 2# I/O
A34 FRAME# I/O B34 Ground
A35 Ground B35 IRDY# I/O
A36 TRDY# I/O B36 +3.3 V dc
A37 Ground B37 DEVSEL# I/O
A38 STOP# I/O B38 Ground
A39 +3.3 V dc B39 LOCK# I/O
A40 SMBCLK1 I/O B40 PERR# I/O
A41 SMBDATA1 I/O B41 +3.3 V dc
A42 Ground B42 SERR# I/O
A43 PAR B43 +3.3 V dc
A44 Address/data 15 I/O B44 C/BE 1# I/O
A45 +3.3 V dc I/O B45 Address/data 14 I/O
A46 Address/data 13 B46 Ground
A47 Address/data 11 I/O B47 Address/data 12 I/O
A48 Ground I/O B48 Address/data 10 I/O
A49 Address/data 9 B49 Ground
A50 Key B50 Key
A51 Key B51 Key
A52 C/BE(0)# I/O B52 Address/data 8 I/O
A53 +3.3 V dc I/O B53 Address/data 7 I/O
A54 Address/data 6 B54 +3.3 V dc
A55 Address/data 4 I/O B55 Address/data 5 I/O
A56 Ground I/O B56 Address/data 3 I/O
A57 Address/data 2 B57 Ground
A58 Address/data 0 I/O B58 Address/data 1 I/O
A59 +5 V dc B59 +5 V dc
A60 ACK64# I/O B60 ACK64# I/O
A61 +5 V dc B61 +5 V dc
A62 +5 V dc B62 +5 V dc
A63 TXD0 B63 RXD0
A64 TXD1 B64 RXC1
A65 TXD2 B65 RXD2
A66 LAN_CLK I/O B66 LAN_RSTSYNC
A67 Ground B67 Ground
A68 EE_DOUT B68 EE_SHCLK
Table 23. 64-bit PCI connector-pin assignments
Pin Signal I/O Pin Signal I/O

IBM NetVista Specifications

General

Category	Desktop
Model	NetVista
Processor Type	Intel Celeron
Memory Type	SDRAM
Optical Drive	CD-ROM, DVD-ROM, or CD-RW
Graphics	Integrated Intel graphics
Audio	Integrated audio
Network	10/100 Ethernet
Operating System	Windows 2000, Windows XP (Varies by model)
Expansion Slots	PCI
Ports	USB, serial, parallel, VGA, audio in/out
