The total width of the server, with cables installed, is 21 inches, as shown in Figure 2-15.
Figure 2-15 Front view of the rack with SMP cables overlapping the rack rails
SMP
Cable
Drawer 1  B Left
to
Drawer 3  A
Left
SMP
Cable
Drawer 2  B Left
to
Drawer 3  B
Left
SMP
Cable
Drawer 1  A Left
to
Drawer 4  A
Left
SMP
Cable
Drawer 3  A Right
to
Drawer 4  A
Right
SMP
Cable
Drawer 2  A Right
to
Drawer 4  B
Right
SMP
Cable
Drawer 1  B Right
to
Drawer 2  B
Right
