IBM SAN48C-6 User Manual

Figure 1. Front View of the IBM SAN48C-6 Switch
1
Serial console port 7 Activity status LED
2 System status LED 8 Ethernet management ports (2)
3 Power status LED 9 Fixed FC ports
4 Fan status LED 10 FC port status LEDs (48)
5 USB port 11 Airflow grill
6 Link status LED
Rear View
The following gure shows the rear view of a IBM SAN48C-6Cisco MDS 9148T Switch Switch:
Figure 2. Rear View of the IBM SAN48C-6Cisco MDS 9148T Switch Switch
1
Power supply failure status LED 6 Power supply status LED
2 IBM Storage Networking: IBM Storage Networking SAN48C-6 32 Gbps 48-Port Fibre Channel Switch
Installation, Service, and User Guide

IBM SAN48C-6 Specifications

General

Brand	IBM
Model	SAN48C-6
Category	Switch
Language	English
