Table 13. Optical Parameters for 16 Gbps SFP+ Transceivers
SFP+ Average
Transmit Power
(dBm)
Average
Receive Power
(dBm)
Fiber-Loss Budget (dB)
Min Max Min Max (62.5 microns
[OM1])
(50.0 microns
[OM2])
(50.0 microns
[OM3])
AJHB -7.8 -1.3 -10.3 0 2.08 (4 Gbps)
1.68 (8 Gbps)
1.63 (16
Gbps)
2.08 (4 Gbps)
1.68 (8 Gbps)
1.63 (16 Gbps)
2.88 (4 Gbps)
2.04 (8 Gbps)
1.86 (16 Gbps)
AJHC -5.0 2.0 -12.0 2.0 7.8 (4 Gbps)
6.4 (8 Gbps)
6.4 (16 Gbps)
AJHD -2.0 5.0 -14.0 2.0 10 (16 Gbps) - -
The following table provides information on operating and storage temperature ranges:
Table 14. Operating and Storage Temperature Ranges for 16 Gbps SFP+ Transceivers
SFP+ Operating Storage
Min Max Min Max
AJHB 0°C 40°C -40°C 85°C
AJHC 0°C 40°C -40°C 85°C
AJHD 0°C 40°C -40°C 85°C
General Specications for Fibre Channel 8 Gbps SFP+ Transceivers
The following table summarizes cabling specications for 8 Gbps transceivers:
Chapter 5. Technical
Specications 43
