Power Requirements and Environmental Conditions for 32 Gbps SFPs
The following table provides the optical parameters for 32 Gbps SFPs:
Table 10. Optical Parameters for 32 Gbps SFPs
SFP+ Average
Transmit Power
(dBm)
Average Receive
Power (dBm)
Fiber-Loss Budget (dB)
Min Max Min Max OM2 OM3 OM4 OM5
AJHE -6.2 2.0 -8.2 2.0 1.68 (8
Gbps)
1.63 (16
Gbps)
2.02 (32
Gbps)
2.04 (8 Gbps)
1.86 (16
Gbps)
1.86 (32
Gbps)
2.04 (8
Gbps)
1.95 (16
Gbps)
1.86 (32
Gbps)
2.04 (8
Gbps)
1.95 (16
Gbps)
1.86 (32
Gbps)
AJHF -5.0 2.0 -11.4 2.0 6.4 (8 Gbps)
6.4 (16 Gbps)
6.4 (32 Gbps)
AJHS -2.0 5.0 -14.0 2.0 10 (16 Gbps)
The following table provides information on operating and storage temperature ranges for 32 Gbps SFPs:
Table 11. Operating and Storage Temperature Ranges for 32 Gbps SFPs
SFP+ Operating Storage
Min Max Min Max
AJHE 0°C 40°C -40°C 70°C
AJHD
0°C 40°C -40°C 70°C
General Specications for Fibre Channel 16 Gbps SFP+ Transceivers
The following table summarizes cabling specications for 16 Gbps SFP+ transceivers:
Chapter 5. Technical
Specications 41
