IBM SAN48C-6 User Manual

Table 2. Chassis Activity LEDs for a IBM SAN48C-6 Switch (continued)
Indicator Location Function Color Status State
PSU Status
Indicators
Faceplate of
each PSU
PSU input/output Green Off No input to the PSU.
Solid on PSU output is OK.
Blinking PSU output is not OK, but
input is OK.
PSU operation Amber Off PSU is operating normally.
Solid on One of the following
conditions exists in the
PSU:
• Over voltage
• Over current
• Over temperature
• Fan failure.
Blinking PSU has a fault, but is still
operational.
Fan Status Faceplate of
each fan module
Fan module Green Solid on Fan module is operating
normally.
Amber Solid on The fan in the fan module
has failed.
The following table describes the Ethernet port LEDs for an IBM SAN48C-6 Fan switch.
LED Position
Status State
Left Off There is no link.
Solid Green Indicates a physical link.
Right Off There is no link trafc.
Blinking Yellow Indicates link trafc.
The following table describes the Fibre Channel port LEDs for an IBM SAN48C-6 switch.
Status
State
Solid Green The link is up.
Regular Blinking Green The link is up and the port beacon is active.
Intermittent Blinking Green The link is up (and trafc is flowing through the port).
Solid Orange The link is disabled by the software.
Blinking Orange A fault condition exists.
Off No link.
Transceivers
SFP+ transceivers are eld replaceable. You can use any combination of SFP+ transceivers that are
supported by the switch. The only restrictions are that SWL transceivers must be paired with SWL
Chapter 1. Overview of the IBM SAN48C-6 Fibre Channel Switch
7
