Component Power Requirements and Heat Dissipation
Consider heat dissipation when sizing the air-conditioning requirements for an installation. The power and
heat associated with a IBM SAN48C-6 32 Gbps 48 Port Fibre Channel Switch varies based on the
following considerations:
• The environment (temperature) outside the chassis
• Internal chassis temperature
• Any hardware component failure in the chassis
• Average switching trafc levels
The following table lists the power requirements and heat dissipation for the components of the IBM
SAN48C-6 32 Gbps 48 Port Fibre Channel Switch.
Table 7. Power Requirements and Heat Dissipation for the IBM SAN48C-6SAN48C-6 32 Gbps 48 Port Fibre
Channel Switch
Module Type/
Product
Number
Power Required
(watts)
Heat
Dissipation
(BTU/hr)
Input Current
85VAC(amps) 110VAC(amps) 220VAC(amps)
IBM SAN48C-6
32 Gbps 48 Port
Fibre Channel
Switch
290 maximum 989 3.41 2.63 1.31
Transceiver Specications
IBM provided transceivers support 850 to 1610 nm nominal wavelengths, depending upon the
transceiver.
For the list of supported transceivers, see the Cisco MDS 9000 Series Compatibility Matrix.
For details about transceivers see the Cisco MDS 9000 Family Pluggable Transceivers Data Sheet.
For information about safety, regulatory, and standards compliance, see the Regulatory Compliance and
Safety Information for the Cisco MDS 9000 Family.
Fibre Channel SFP+ Transceivers
The following table lists the Fibre Channel SFP+ transceivers that are available for the IBM
SAN48C-6SAN48C-6 switch:
Table 8. Fibre Channel SFP + Transceivers for the IBM SAN48C-6SAN48C-6 Switch
Feature Code Description Type
AJHE 32 Gbps Fibre Channel SW SFP+ Short wavelength
AJHF 32 Gbps Fibre Channel LW SFP+ Long wavelength
AJHB 16 Gbps Fibre Channel SW, SFP+ Short wavelength
AJHC 16 Gbps Fibre Channel LW, SFP+ Long wavelength
AJHM 8 Gbps Fibre Channel SW, SFP+ Short wavelength
AJHN 8 Gbps Fibre Channel LW, SFP+ Long wavelength
AJHS 32 Gbps Fibre Channel ELW SFP+ Extended Long wavelength
AJHD 16 Gbps Fibre Channel ELW SFP+ Extended Long wavelength
Chapter 5. Technical Specications 39
