IBM SAN48C-6 User Manual

Note: IBM SAN48C-6 does not support 4 Gbps Fibre Channel SW SFP+.
General Specications for Fibre Channel 32 Gbps SFP+ Transceivers
The following table summarizes cabling specications for 32 Gbps.
Table 9. General Specications for 32 Gbps Fibre Channel SFP+ Transceivers
SFP+ Wavelength
(nm)
Fibre Type Core Size
(microns)
Baud Rate
(GBd)
Cable Distance
AJHE 850 MMF 50.0 28.05 65 ft (20 m)
(OM2)
50.0 28.05 230 ft (70 m)
(OM3)
50.0 28.05 328 ft (100 m)
(OM4)
50.0 28.05 328 ft (100 m)
(OM5)
62.5 14.025 49 ft (15 m)
(OM1)
50.0 14.025 115 ft (35 m)
(OM2)
50.0 14.025 328 ft (100 m)
(OM3)
50.0 14.025 410 ft (125 m)
(OM4)
50.0 14.025 410 ft (125 m)
(OM5)
62.5 8.5 69 ft (21 m)
(OM1)
50.0 8.5 164 ft (50 m)
(OM2)
50.0 8.5 492 ft (150 m)
(OM3)
50.0 8.5 623 ft (190 m)
(OM4)
50.0 8.5 623 ft (190 m)
(OM5)
AJHF 1310 SMF 9.0
9.0
9.0
28.05
14.025
8.5
10 km (6.2 mi)
10 km (6.2 mi)
10 km (6.2 mi)
AJHS 1310 SMF 9.0
9.0
9.0
28.05
14.025
4.25
15.5 mi (25 km)
15.5 mi (25 km)
15.5 mi (25 km)
40 IBM Storage Networking: IBM Storage Networking SAN48C-6 32 Gbps 48-Port Fibre Channel Switch
Installation, Service, and User Guide
