d.
Head
play
-
it
should be
.045"
measured
at
the
typehead
skirt.
If
excessive
head
play
is
suspected
the
ball joint should he
replaced
and
the
typehead
homing
adjustment
refined.
CAUTION:
Excessively
advanced
or
retarded
tim-
i ng
can
cause
parts
damage
as we
II
as poor
hori-
zonta
alignment
or
improper
selection.
This
could
happen
if
the
detent
entered
the
wrong
notch
or
re-
mained
in
the
notch
too
long.
NOTE:
Be
sure
to
maintain
.002"
to
.004"
end
play
in
the
print
shaft.
14.
Shift Motion - The shift arm
adjusting
screw
(Fig.
132)
should be
adjusted
in
or
out
to
obtain
180
0
rotation
of
the
typeh'3ad
during
a shift
operation.
Lock
Nut
LA
TE
STYLE
FIGURE 132.
Shift
Motion
Adjustment
The
adjustment
can
be
checked
by
observing
the
detent-
ing
in
the
lower
case
compared
to
the
upper
case
using
a
-5
character.
The
detent
MUST
enter
the
lower
case
notch
EXACTLY
the
same as
it
does
the
upper
case
notch.
Check
by
half-cycling
the
machine
cmd
manually
with-
drawing
the
detent.
Remove
the
head
play
clockwise
and
allow
the
detent
to
re-enter
slowly.
A final
check
can
be
made by
comparing
the
detent
withdrawal
timing
ofthe
upper
and
lower
case.
They must be
exactly
al
ike.
Maladjustment
can
cause
misal ignment in
the
lower
case
while
the
upper
case
remains
good.
CAUTION:
Be
sure
that
the
shift cam is
detented
at
each
position
during
the
check
and
that
the
cycle
shaft
is
properly
latched
at
the
half-cycle
position.
15.
Final
Check
-
After
completing
the
foregoing
adjust-
ments,
a final
check
should be made
to
see
if
any
re-
finements
are
necessary.
Compare
the
coarse
al
ignment
of
0
rotate
compared
to
+5,
-1,
-3,
-4,
-5.
The
band
wi dth
of
th
i s
group
shou I d
not
exceed
.030"
and
none
of
the
group
should
detent
closer
than
.010"
to
the
center
of
the
notch
when
the
head
play
is removed in
the
nega-
tive
dl,
.:-dion.
The following
table
can
be used
to
diagnose
the
cause
of
excessive
band
width
between
a 0
rotate
and
+5,
-1,
-3,
2-41
-4,
-5.
If an
excessive
band
width
exists,
it
will be
greatest
among
these
characters.
In
making
the
diagnosis
follow
the
sequence
as
listed.
Excessive Band
Width
Between
o
(zero)
and
-1
-3
and
+5
-3,
+5
and
0
(zero)
-5
and
-3
Cause
Incorrect
balance
Incorrect
rotate
arm motion
Incorrect
latch
clearances
Incorrect
paddle
adjustmenl
Unwanted
compensator
roller
droppage
may
result
from
one
or
more
of
the
following.
a.
Improper
detent
timing
b.
Malselection
(popping
latches)
c.
Incorrect
rotate
spring
tension
or
damper
spring
ten-
sion.
d.
Binds in
the
typehead,
upper
bal I
socket,
rotate
shaft,
rotate
pulley,
or
rotate
spring.
e.
Binds in
the
compensator
or
lever
system.
f. Loose
differential
mounting
bracket.
g.
Excessive
band
width
or
head
play.
If
the
band
width
appears
to
be
all
right but
the
align-
ment
is
not
satisfactory,
check
the
following
items:
a.
Detent
timing
b.
Playorbindsinthe
tilt
or
rotate
detents.
Side
play
in
the
rotate
detent
can
be
checked
by
holding
down
the
interposer
for
the
letter
"N"
so
that
it
repeats
for a full
line.
Move
the
carrier
back
manually
and
repeat
the
operation
without
indexing.
The
second
I
ine
should
cover
the
first I ine
exactly.
If
any
of
the
characters
are
shadowed,
side
play
in
the
rotate
detent
cou
I d be
the
cause.
c.
Loose
fitting
upper
ball
socket.
d.
Excessive
play
in
the
carrier
or
rocker.
e.
Binds in
the
rocker
parts.
f.
If
the
-5
characters
vary
horizontally,
improper
damper
spring
tension
could
be
the
cause.
g.
Improper
tilt
adjustments
can
cause
poor
horizontal
al ignment by
delaying
the
detent
seating.
NOTE:
After
the
machine
has
been
in use for some
time,
wear
in
the
tape
system will
allow
the
typehead
to
drift
in
the
negative
direction.
It
is
not
necessary
to
slip
the
rotate
shaft
within
the
rotate
pulley
to
REFINE
the
typehead
position.
The
proper
position may
be
gain-
edbyrefining
the
eccentric
stud
adjustment.
Be
sure
to
RESEATthe
compensator
roller
after
changing
the
eccen-
tric
stud
adjustment.
(Maintain
the
roller
position
1/16"
from
the
topofthe
slot
by
adjustment
of
the
rotate
link.)
