Release
tabs
Hard disk drive
fan assembly
Slot
8. Remove the cable from the slot on the hard disk drive fan assembly; then,
rotate the assembly away from the drive cage and remove the assembly from
the drive cage.
9. If you are instructed to return the hard disk drive fan assembly, follow all
packaging instructions, and use any packaging materials for shipping that are
supplied to you.
82 System x3200 M2 Types 4367 and 4368: Problem Determination and Service Guide
