IBM x3200 M2 Type 4367 - System-Board External Connectors

System-board external connectors
The following illustration shows the external input/output (I/O) connectors on the
system board.
Serial 2 (Com2)
Serial 1 (Com1)
Video
USB 3 and 4
USB 1 and 2
Remote
Supervisor
Adapter II
SlimLine
(Ethernet)
Ethernet
connector
Parallel
Power cord
AC power LED
DC power LED
Ethernet transmit/
receive activity LED
(amber)
Ethernet link
status LED
(green)
10 System x3200 M2 Types 4367 and 4368: Problem Determination and Service Guide
