IBM x3200 M2 Type 4367 - System-Board Optional-Devices Connectors

System-board optional-devices connectors
The following illustration shows the system-board connectors for user-installable
optional devices.
DIMM 1
DIMM 2
DIMM 3
DIMM 4
Slot 5, PCI 32-bit 33 MHz
Slot 4, PCI 32-bit 33 MHz
Slot 3, PCI-X 64-bit 133 MHz
Slot 2, PCI Express x4 (x1)
Slot 1, PCI Express x8
Remote Supervisor
Adapter II Slim Line
Chapter 1. Introduction 11
