Table 5. Parts listing, Types 4367 and 4368 (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
9 Hard disk drive, SAS, 3.5-inch 146 GB, 15K, hot-swap,
with tray (optional)
39R7350
9 Hard disk drive, SAS, 3.5-inch 300 GB, 15K, hot-swap,
with tray (optional)
43X0805
9 Hard disk drive, SAS, 2.5-inch 73 GB, 10K, hot-swap, with
tray (optional)
39R7366
9 Hard disk drive, SAS, 2.5-inch 146 GB, 10K, hot-swap,
with tray (optional)
43X0825
9 Hard disk drive, SAS, 2.5-inch 73 GB, 15K, hot-swap, with
tray (type 4368 model E4x
43X0839
10 Retention bracket (front), adapter 13N2993
11 Hard disk drive cage, 3.5-inch drives (type 4367 models
22x, 32x, 34x, 36x, 38x, 42x, 54x, 72x, B2x, BDx, C2x,
D2x, E1x, E2x) (type 4368 models B2x C2x 22x 32x 34x
36x, 38x, 42x, 54x, 72x, B2x, BDx, C2x, CDx, D2x, E1x,
E2x, E3x, E6x)
42C8910
11 Hard disk drive cage, 2.5-inch drives (four bays) (type
4367 models 52x 74x 76x 84x) (type 4368 models 52x,
74x, 76x, 84x, E4x)
42C8911
11 Hard disk drive cage, 2.5-inch drives (eight bays)
(optional)
44E7299
12 Hard disk drive backplane (for 2.5-inch and 3.5 in
Hot-Swap SAS/SATA hard disk drives) (type 4367 models
34x, 38x, 42x, 52x, 54x, 72x, 74x, 76x, 84x, D2x) (type
4368 models 34x, 38x, 42x, 52x, 54x, 72x, 74x, 76x, 84x,
D2x, E1x, E2x, E4x, E6x)
44E8783
12 Hard disk drive backplate (for 3.5-inch Simple-Swap SATA
hard disk drives) (type 4367 models 22x, 32x, 36x, B2x,
BDx, C2x, CDx, E1x, E2x, E3x) (type 4368 models 22x,
32x, 36x, B2x, BDx, C2x, CDx, E1x, E2x, E3x, E3x)
25R8842
13 Hard disk drive fan assembly (for 3.5-inch drive cage)
(type 4367 models 2x, 32x, 34x, 36x, 38x, 42x, 54x, 72x,
B2x, BDx, C2x, CDx, D2x, E1x, E2x) (type 4368 models
22x, 32x, 34x, 36x, 38x, 42x, 54x, 72x, B2x, BDx, C2x,
CDx, D2x, E1x, E2x, E3x, E6x)
39Y9860
13 Hard disk drive fan assembly (for 2.5-inch drive cage with
4 bays) (type 4367 models 52x, 74x, 76x, 84x) (type 4368
models 52x, 74x, 76x, 84x, E4x)
42C7507
13 Hard disk drive fan assembly (for 2.5-inch drive cage with
8 bays) (optional)
44E7301
14 System board assembly (all models) 44E7312
15 LSI SAS/SATA RAID 01 controller (type 4367 models 34x,
38x, 42x, 52x, 54x, 72x, 74x, 76x, 84x, D2x) (type 4368
models 34x, 38x, 42x, 52x, 54x, 72x, 74x, 76x, 84x, D2x,
E1x, E2x, E4x, E6x)
43V7415
16 Microprocessor, 800 MHz/1M, 2.2 GHz dual-core (type
4367 models B2x, E2x) (type 4368 models B2x, E6x)
46C1259
Chapter 3. Parts listing, System x3200 M2 Types 4367 and 4368 35

IBM x3200 M2 Type 4367 Specifications

General

Processor	Intel Xeon 3000 Sequence, Intel Core 2 Duo, Intel Pentium Dual-Core
Memory Slots	4 DIMM slots
Chipset	Intel 3200
Storage Controller	Integrated SATA controller
Form Factor	Tower
Memory	Up to 8GB DDR2
Storage	SATA
Hard Drive Bays	4
RAID Support	RAID 0, 1
Network Controller	Integrated Broadcom Gigabit Ethernet
Expansion Slots	1 PCI-Express x8, 1 PCI-Express x1, 2 PCI
Power Supply	400W fixed
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor Cores	Dual-core, Quad-core (Xeon 3200 series)
