Table 5. Parts listing, Types 4367 and 4368 (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
Bracket, RSA2 (all models) 41Y9086
Cable, 18-inch SATA signal (all models) 39Y9810
Cable, 1Mx4 SAS-Mini (optional) 39R6530
Cable, 3Mx4 SAS-Mini (optional) 39R6532
Cable, 2nd serial port (all models) 42C1053
Cable, 401 watt DAS (for non-redundant power supply
and hot-swap drives connection) (type 4367 models 34x,
38x, 42x, 52x, 72x, 76x) (type 4368 models 34x, 38x, 42x,
52x, 72x, 76x, E1x, E6x)
25R8849
Cable, diskette drive (optional) 39Y9728
Cable, interposer (optional) 44E7578
Cable, mini-SAS/SATA 4X signal (type 4367 models 24x,
38x, 42x, 52x, 54x, 72x, 74x, 76x, 84x, D2x) (type 4368
models 24x, 38x, 42x, 52x, 54x, 72x, 74x, 76x, 84x, D2x,
E2x, E4x, E6x)
41Y3884
Cable, panel mount assembly SATA (type 4367 models
22x, 32x, 36x, B2x, BDx, C2x, CDx, E1x, E2x) (type 4368
models 22x, 32x, 36x, B2x, BDx, C2x, CDx, E3x)
13N2413
Carrier, battery (optional) 80Y9304
EMC I/O shield (for system I/O ports) (all models) 25R8843
EMC shield kit (for 5.25 in. and 3.5 in. drive bays) 13N2997
Feet, chassis 13N2985
Hard drive carrier assembly (all models) 42C7495
Keyboard, US (optional) 42C0060
Keyboard, US UltraNav USB, with TrackPoint and
TouchPad (optional)
40K9400
Keylock, keyed-alike (optional) 26K7363
Keylock, keyed-random (all models) 26K7364
Kit, Retainer (for optical and diskette drives) (all models) 39R9369
38 System x3200 M2 Types 4367 and 4368: Problem Determination and Service Guide
