IBM x3850 X5 7145 User Manual

The following illustration shows the locations of the input and output connectors on
the rear of the server.
AC
DC
!
System
management
Ethernet
System
serial
Video USB
Gigabit
Ethernet 1 - 2
Power
connector
AC
DC
!
QPI
ports
1 - 2
QPI
ports
3 - 4
Updating the server configuration
When you start the server for the first time after you add or remove a device, you
might receive a message that the configuration has changed. The Setup utility
starts automatically so that you can save the new configuration settings. For more
information, see Chapter 3, “Configuring the server,” on page 61.
Some optional devices have device drivers that you must install. For information
about installing device drivers, see the documentation that comes with each device.
The server comes with at least one microprocessor. If more than one
microprocessor is installed, the server can operate as a symmetric multiprocessing
(SMP) server. You might have to upgrade the operating system to support SMP. For
more information, see “Typical operating-system installation” on page 69 and the
operating-system documentation.
If the server has an optional RAID adapter and you have installed or removed a
hard disk drive, see the documentation that comes with the RAID adapter for
information about reconfiguring the disk arrays.
For information about configuring the integrated Gigabit Ethernet controller, see
“Configuring the Broadcom Gigabit Ethernet controller” on page 72.
60 IBM System x3850 X5 and x3950 X5 Types 7145 and 7146: Installation and User’s Guide

IBM x3850 X5 7145 Specifications

General

Processor	Intel Xeon E7-4800 series
Form Factor	4U Rack
Network Interface	Integrated dual-port Gigabit Ethernet
Chipset	Intel 7500
Memory Type	DDR3
Max Processors	4
Storage	Up to 8 HDDs or SSDs
RAID Support	RAID 0, 1, 5, 6, 10
Memory	Up to 1TB DDR3
