The conﬁguration mode is used to set the SC2210 to match your heating/cooling system. The SC2210 functions with up

to 3-stage heat pump systems.

To conﬁgure the SC2210, perform the following steps:

1. Slide the Mode switch to the OFF position.

2. Remove the cover of the thermostat by gently pulling on one of the corners.

3. S

imultaneously hold the SW5 and SW6 buttons in for 5 seconds while the SC2210 is in OFF mode.

4. Press the or button to change settings within each screen.

5. Press the

SW6

button to advance to the next screen.

Note: The

SW5

button will return you to the previous screen.

6. To exit conﬁguration mode, slide the Mode switch to Heat or Cool.

Conﬁguration Mode Settings

The setup screens for Conﬁguration Mode are as follows:

1. Temperature Scale (F or C) – Choose Fahrenheit or Celsius.

Press the or button to select.

Press the

SW6

button to advance to the next screen.

FILTER

DIFF

ROOM

SET

REMOTE

FILTER

DIFF

ROOM

SET

REMOTE

3. Temperature Differential – Stage 2 – (1°F to 6°F) (0.5°C to 3.0°C) –

Set the number of degrees between when stage 1 turns on and stage

2 turns on.

Press the or button to set differential value.

Press the

SW6

button to advance to the next screen.

FILTER

DIFF

ROOM

SET

REMOTE

FILTER

DIFF

ROOM

SET

REMOTE

2. Temperature Differential – Stage 1 – (1°F to 3°F) (0.5°C to 1.5°C) –

Set the number of degrees between your “setpoint” temperature and

your “turn on” temperature for ﬁrst stage.

Press the or button to set differential value.

Press the

SW6

button to advance to the next screen.

FILTER

DIFF

ROOM

SET

REMOTE

Conguration Mode
