6
120
VAC
24 VAC
Reversing Valve
Fan
Compressor
Auxiliary Heat #1
Single Compressor
heat pump with electric backup
Dual Compressor
heat pump with electric backup
120
VAC
24 VAC
Reversing Valve
Compressor #1
Emergency Heat
Fan
Compressor #2
Transformer
Optional
remote or
outdoor sensor
Transformer
Optional
remote or
outdoor sensor
* outdoor sensor only reads outdoor temperature
