Icom IC-705 - UTC Offset Setting; Remote MIC Key Setting; Color Settings; Bandscope Edge Frequency Settings

20
REMOTE CONTROL
Remote control (CI-V) information
D Command formats
• UTC Offset setting
Command: 1A 05 0170
Shift direction
00=+ (plus)
01=− (minus)
Offset time
0000 ~ 1400
XX X X XX
• Remote MIC Key setting
Command: 1A 05 0074 ~ 0077
Data Function
00 No function
01 UP
02 DOWN
03 UP (VFO: kHz)
04 DOWN (VFO: kHz)
05
VOL UP
06
VOL DOWN
07
XFC
08
CALL
09 VFO/MEMO
10 DR
11 FROM/TO (DR)
12 Home CH
13 BAND/GROUP UP
14 BAND/GROUP DOWN
15 SCAN
16 Temporary Skip
17 SPEECH
18 MODE
19 RF Power
20 Voice TX (T1)
21 Voice TX (T2)
22 Keyer Memory (M1)
23 Keyer Memory (M2)
24 T-CALL*
25 RX>CS
26 TS
27 MPAD
28 SPLIT
29 A/B
* Only for European version�
• Color settings
Command: 1A 05 0180, 0181, 0182, 0240,
0242, 0258, 0262, 0263
1
0 X X X 0 X X X 0 X X X
2 3 4 5 6
R (Red)
0000 ~ 0255
G (Green)
0000 ~ 0255
B (Blue)
0000 ~ 0255
• Bandscope edge frequency settings
Command: 1A 05 0188 ~ 1A 05 0238
1 kHz: 0
~
9
100 Hz: 0 (fixed) 100 kHz: 0
~ 9
10 kHz: 0
~ 9
10 MHz: 0
~ 9
1 MHz: 0
~ 9
1 GHz: 0 (fixed) 100 MHz: 0
~ 4
1 kHz: 0
~ 9
100 Hz: 0 (fixed) 100 kHz: 0
~ 9
10 kHz: 0
~ 9
10 MHz: 0
~ 9
1 MHz: 0
~ 9
1 GHz: 0 (fixed) 100 MHz: 0
~ 4
1
X 0 X X X X 0 X X 0 X X
2 3 4 5 6
Lower edge Higher edge
X X 0 X
7 8
