Icom IC-705 Reference Guide

5
REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data Description
19*
1
00 Read the transceiver ID
1A* 00 See pp� 17
and 18�
Send/read memory contents
01 See p� 18�
Send/read band stacking register contents
02*
5
See p� 19� Send/read memory keyer contents
03 See p� 19� Send/read the selected IF filter width
04 See p� 19� Send/read the selected AGC time
constant
05 SET > Tone Control/TBW
0001 See p� 19� RX > SSB >
Send/read RX HPF/LPF settings
0002 00 ~ 10 RX > SSB >
Send/read RX Tone (Bass) level
(00=–5 ~ 10=+5)
0003 00 ~ 10 RX > SSB >
Send/read RX Tone (Treble) level
(00=–5 ~ 10=+5)
0004 See p� 19� RX > AM >
Send/read RX HPF/LPF settings
0005 00 ~ 10 RX > AM >
Send/read RX Tone (Bass) level
(00=–5 ~ 10=+5)
0006 00 ~ 10 RX > AM >
Send/read RX Tone (Treble) level
(00=–5 ~ 10=+5)
0007 See p� 19� RX > FM >
Send/read RX HPF/LPF settings
0008 00 ~ 10 RX > FM >
Send/read RX Tone (Bass) level
(00=–5 ~ 10=+5)
0009 00 ~ 10 RX > FM >
Send/read RX Tone (Treble) level
(00=–5 ~ 10=+5)
0010 See p� 19� RX > DV >
Send/read RX HPF/LPF settings
0011 00 ~ 10 RX > DV >
Send/read RX Tone (Bass) level
(00=–5 ~ 10=+5)
0012 00 ~ 10 RX > DV >
Send/read RX Tone (Treble) level
(00=–5 ~ 10=+5)
0013 00 ~ 10 RX > WFM >
Send/read RX Tone (Bass) level
(00=–5 ~ 10=+5)
0014 00 ~ 10 RX > WFM >
Send/read RX Tone (Treble) level
(00=–5 ~ 10=+5)
0015 See p� 19� RX > CW >
Send/read RX HPF/LPF settings
0016 See p� 19� RX > RTTY >
Send/read RX HPF/LPF settings
0017 00 ~ 10 TX > SSB >
Send/read TX Tone (Bass) level
(00=–5 ~ 10=+5)
0018 00 ~ 10 TX > SSB >
Send/read TX Tone (Treble) level
(00=–5 ~ 10=+5)
0019 See p� 19� TX > SSB >
Send/read TX bandwidth for wide
Cmd� Sub cmd� Data Description
1A* 05 SET > Tone Control/TBW
0020 See p� 19� TX > SSB >
Send/read TX bandwidth for mid
0021 See p� 19� TX > SSB >
Send/read TX bandwidth for narrow
0022 See p� 19� TX > SSB-D >
Send/read TX bandwidth
0023 00 ~ 10 TX > AM >
Send/read TX Tone (Bass) level
(00=–5 ~ 10=+5)
0024 00 ~ 10 TX > AM >
Send/read TX Tone (Treble) level
(00=–5 ~ 10=+5)
0025 00 ~ 10 TX > FM >
Send/read TX Tone (Bass) level
(00=–5 ~ 10=+5)
0026 00 ~ 10 TX > FM >
Send/read TX Tone (Treble) level
(00=–5 ~ 10=+5)
0027 00 ~ 10 TX > DV >
Send/read TX Tone (Bass) level
(00=–5 ~ 10=+5)
0028 00 ~ 10 TX > DV >
Send/read TX Tone (Treble) level
(00=–5 ~ 10=+5)
SET > Function
0029 0000 ~ 0255
Send/read the Beep Level setting
(0000=Minimum ~ 0255=Maximum)
0030 00/01 Send/read the Beep Level Limit
setting
(00=OFF, 01=ON)
0031 00/01 Send/read the Beep (Confirmation)
setting
(00=OFF, 01=ON)
0032 00/01 Send/read the Home CH Beep
setting
(00=OFF, 01=ON)
0033 00 ~ 03 Send/read the Band Edge Beep
setting
( 00=OFF, 01=ON (Default),
02=ON (User),
03=ON (User) & TX Limit)
0034 00 ~ 04 Send/read the Auto Power OFF
setting
( 00=OFF, 01=30 min, 02=60 min,
03=90 min, 04=120 min)
0035 00 ~ 03 Send/read the Power Save setting
( 00=OFF, 01=Auto (Short),
02=Auto (Middle), 03=Auto (Long))
0036 00 ~ 03 Send/read the Max TX Power
(Battery Pack) setting
( 00=0�5 W, 01=1 W, 02=2�5 W,
03=5 W)
0037 00 ~ 04 Send/read the Max TX Power (DC
13�8V) setting
( 00=0�5 W, 01=1 W, 02=2�5 W,
03=5 W, 04=10 W)
0038 00 ~ 05 Send/read the TX Delay (HF) setting
( 00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)

Icom IC-705 Specifications

General

Bluetooth	Yes
WLAN	Yes
SD Card Slot	Yes
Antenna Connector	BNC
Frequency Range	0.030–199.999 MHz
Modes	SSB, CW, AM, FM
Receiver Type	Superheterodyne
GPS	Built-in
Battery	Lithium-ion
Weight	Approx. 1.1 kg
Type	Portable
Power Supply	13.8 V DC
Waterproof Standard	IP54
Operating Temperature Range	-10°C to +60°C
Display	4.3 inch color TFT touch screen LCD
