5 - 7
CP3701
CW carrier
check point
R3703
CW carrier
adjustment
R1730
AM carrier
adjustment
R2321
AM modulation adjustment
(or AM carrier pre-setting)
AM modulation adjustment
(or AM carrier pre-setting)
R2385
R2303
Carrier suppression
adjustment
• MAIN unit
