Page #37 background imageLoading...
Page #37 background image
32
10
SPECIFICATIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
D General
• Frequency coverage : 118.000 to 136.975 MHz
• Mode : 6K00A3E
• Channel spacing : 25 kHz
• Number of memory channels :
IC-A15 200 (20 CH × 10 BANKS)
IC-A15S 100
• Power supply requirement : Specified Icom’s battery packs
7.4 V DC standard
• Usable temperature range : –20˚C to +55˚C
• Current drain (at 7.4 V DC) :
Tx 1.5 A
Rx at stand by 50 mA typical
at AF max. 500 mA
• Antenna connector : BNC 50 Ω (nominal)
Dimensions : 53(W) × 120(H) × 36.9(D) mm
(projections not included)
Weight : Approx. 180 g
(Without the battery pack and antenna.)
D Transmitter
• Output power : 5.0 W (PEP) typical
1.5 W (CW)
• Modulation : Low level modulation
• Modulation depth : 85%
• Frequency stability : ±5 ppm
• Audio harmonic distortion : Less than 10% (at 85%+3 dB mod.)
• Harmonic spurious emissions : Less than –36 dBm (except operat-
ing frequency ±1 MHz range)
• External MIC connector : 3-conductor 2.5(d) mm (
1
10˝)/
150 Ω
D Receiver
• Receive system : Double conversion superhetero-
dyne
• Intermediate frequencies : 1st 46.35 MHz, 2nd 450 kHz
• Sensitivity (12 dB SINAD) : –3 dBµ typical
• Squelch sensitivity (threshold) : Less than 0 dBµ
• Selectivity : 6 dB (More than 7.5 kHz)
60 dB (Less than 25 kHz)
• Spurious response rejection : More than 70 dB
Audio output power : More than 700 mW (internal SP)
( at 10% distortion with an 8 Ω More than 500 mW (external SP)
load, 30% mod.)
• Hum and noise : More than 40 dB at 90% mod.
• External SP connector : 3-conductor 3.5 (d) mm (
1
8˝)/8 Ω
All stated specifications are subject to change without notice or obligation.
