Icom IC-M323 - Menu Screen Items

69
8
MENU SCREEN OPERATION
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
New2001
■ Menu screen items
The Menu screen contains the following items.
DSC Calls D
Item Ref. Item Ref.
•IndividualCall p. 27
• Received Call Log p. 60
•IndividualACK*
1
p. 31 • Position Request Call*
2
p. 35
•GroupCall p. 32
• Position Report Call*
2
p. 37
•AllShipsCall p. 34
• Polling Request Call*
2
p. 59
•DistressCall p. 23 •TestCall p. 41
•TransmittedCallLog p. 59 •TestACK*
1
p. 43
*
1
Displayed only after receiving a corresponding call.
*
2
For only U.S.A and Australian version transceivers.
DSC Settings D
Item Ref. Item Ref.
•PositionInput*
3
p. 22 •TestACK p. 62
•IndividualID p. 19 •CH16Switch p. 63
•GroupID p. 20 •Alarm p. 64
•IndividualACK p. 62 •CH70SQLLevel p. 64
•PositionACK p. 62 •DSCLoopTest p. 65
*
3
Displayed only when no GPS information is received.
Radio Settings D
Item Ref. Item Ref.
•ScanType p. 70 •CHANGroup p. 70
•ScanTimer p. 70 •WXAlert*
2
p. 71
•Dual/Tri-Watch
Configuration D
Item Ref. Item Ref.
•Backlight p. 71 •UTCOffset p. 73
•DisplayContrast p. 71 •InactivityTimer p. 73
•KeyBeep p. 71 •NMEAOutput p. 74
•KeyAssignment p. 72 •RemoteID p. 74
MMSI/GPS Info D
The transceiver shows the preset MMSI and ATIS*
4
codes
and GPS information*
5
.
If the code is not entered, “NO DSC MMSI” or “NO ATIS
MMSI”*
4
is displayed.
*
4
Displayed only for the Dutch and German version transceivers.
*
5
Displayed only when an external GPS receiver or built-in GPS re-
ceiver is receiving valid position data.
Rotate
