Icom IC-M37

22
10
SPECIFICATIONS AND OPTIONS
■ Using the BP-297
When using the optional BP-297 battery case, install 3 × AAA (LR03) size Alkaline batteries.
CAUTION:
• NEVER incinerate used battery cells since internal battery gas
may cause them to rupture.
• NEVER expose a detached battery case to water. If the battery
case gets wet, be sure to wipe it dry before using it.
• NEVER use batteries whose insulated cover is damaged.
• NEVER insert the transceiver into the charger, and charge it
when the optional battery case is attached.
NOTE:
• When installing the batteries, make sure they are all the same brand,
type and capacity. Also, do not mix new and old batteries together.
• Keep the battery terminals clean. It’s a good idea to occasionally
clean them.
• The transceiver may sink when the optional battery case is
attached. (Depends on the weight of the installed batteries.)
• When using the optional battery case, the output power level is
xed at Low power.
D Battery pack/Battery case
• BP-296 li-ion battery pack
Voltage: 3.6 V
Capacity: 2200 mAh (minimum),
2350 mAh (typical)
Battery life: Approximately 12 hours*
* When the Power Save function is ON,
and the operating periods are calculated
under the following conditions:
TX : RX : standby = 5 : 5 : 90
• BP-297
battery case
Battery case for 3 × AAA (LR03) alkaline
batteries.
Some options may not be available in some
countries. Please ask your dealer for details.
D Charger
• BC-235 desktop charger
+BC-217 ac adapter
To rapidly charge a battery pack.
• BC-238
multi charger
+OPC-2416 dc power cable
To rapidly charge a battery pack.
L The AD-138 charger adapters are installed.
D Others
• FA-SC59V antenna
• MB-133 belt clip
• HM-213 speaker microphone
Full sized waterproof speaker
microphone including alligator type clip to
attach to your shirt or collar, and so on.
The HM-213 meets IP57 requirements for
dust protection and waterproof protection.
■ Options
Receiver IC-M37 IC-M37E IC-M37E (AUS)
Adjacent channel selectivity 70 dB (typical) 70 dB 65 dB
Spurious response 70 dB (typical) 70 dB 65 dB
Intermodulation 70 dB (typical) 68 dB 65 dB
Hum and noise 40 dB
Audio frequency response +1 dB ~ –3 dB of –6 dB octave from 300 Hz ~ 3000 Hz
■ Specications
