34
6
DSC OPERATION
D Transmitting a position report call
Transmit a position report call when you want to announce
your own position to a specific ship and to get an answer, etc.
q Push [MENU] to enter the DSC menu.
w Rotate [DIAL] to select “Position Report,” push
[DIAL•ENTER].
e Rotate [DIAL] to select the desired pre-programmed
individual address or “Manual Input,” push
[DIAL•ENTER].
•TheIDcodecanbesetinadvance.(p.17)
•When“Manual Input” is selected, set the 9-digit MMSI
number for the individual you wish to call by rotating [DIAL].
Regardless of a GPS receiver (NMEA0183 ver. 2.0 or
3.01) connection, the current position/time information
appears in steps r and t. If the information is not nec-
essary to be changed, push [DIAL•ENTER] or [16•9]
several times to skip the data input steps.
r The position information appears. Set your position (lati-
tude and longitude) data by rotating [DIAL].
•Push[16•9] or [CH/WX•DUAL•U/I/C] to move the cursor for-
ward or backward, respectively.
•Rotate[DIAL] to edit N; North latitude or S; South latitude when
thecursorisonthe‘N’or‘S’position,andW;Westlongitudeor
E;Eastlongitudewhenthecursorisonthe‘W’or‘E’position.
•Push[CLR] for 1 sec. to clear the latitude/
longitude
data.
•Push[CLR] to cancel and return to the DSC menu.
t After setting the position data, push [DIAL•ENTER] to set
the current UTC time. Set the current UTC time by rotat-
ing [DIAL], then push [DIAL•ENTER].
•Push[16•9] or [CH/WX•DUAL•U/I/C] to move the cursor for-
ward or backward, respectively.
•Push[CLR] for 1 sec. to clear the UTC time data.
•Push[CLR] to cancel and return to the DSC menu.
--DSC Menu--
Input Position
Latitude
__°__.___N Null
Longitude
__°__.___W Null
<CLR 1sec˘Null Data>
<CLR˘Exit / ENT˘OK>
--DSC Menu--
Select Address
Manual Input
John
˘Paul
George
Michael
<CLR˘Exit / ENT˘OK>
--DSC Menu--
Select Item
Position Input
Individual Call
Group Call
All Ships Call
Position Request
˘Position Report
To Next Page
