6 - 1
SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
W1 8900015550 CBL OPC-1658
W2 7120000470 JMP ERDS2T0
W3 7120000470 JMP ERDS2T0
S.=Surface mount
[LOGIC UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R47 7030003360 S.RES ERJ3GEYJ 221 V (220) B 103.8/13
R48 7030003360 S.RES ERJ3GEYJ 221 V (220) B 107.1/49.6
R49 7030003360 S.RES ERJ3GEYJ 221 V (220) B 34.2/22.3
R50 7030003330 S.RES ERJ3GEYJ 121 V (120) B 31/33.5
R51 7030003330 S.RES ERJ3GEYJ 121 V (120) B 63.3/36.6
R52 7030003700 S.RES ERJ3GEYJ 154 V (150 k) B 63.9/38.7
R53 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 65.2/38.7
R55 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 35.6/22.3
R56 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 38.2/22.3
R57 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 40.8/22.3
R58 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 43.4/22.3
R62 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 28.9/44.8
R63 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 34.9/36.9
R64 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 25.9/41.8
R65 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 27.2/41.8
R66 7030003320 S.RES ERJ3GEYJ 101 V (100) B 33.4/35.1
R71 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 60.7/46.2
R72 7030003860 S.RES ERJ3GE JPW V B 58.6/43.7
R81 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 81.9/70.6
R82 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 85.3/70.6
R83 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 83.2/70.6
C2 4030006900 S.CER C1608 JB 1H 103K-T B 106.1/66.5
C4 4030008890 S.CER C1608 JB 1H 273K-T B 88.3/33.9
C5 4510008560 S.ELE EEE1HAR47SR B 88.1/30.8
C6 4030006900 S.CER C1608 JB 1H 103K-T B 84.3/35
C7 4030011600 S.CER C1608 JB 1E 104K-T B 78/65.3
C8 4030011600 S.CER C1608 JB 1E 104K-T B 74.9/63.7
C9 4510008540 S.ELE EEE1CA100SR B 69.7/66.6
C11 4030011600 S.CER C1608 JB 1E 104K-T B 93.4/54.7
C12 4030011600 S.CER C1608 JB 1E 104K-T B 93.1/47.8
C15 4030006850 S.CER C1608 JB 1H 471K-T B 84/39.1
C17 4030011600 S.CER C1608 JB 1E 104K-T B 82.4/41.9
C18 4030007050 S.CER C1608 CH 1H 220J-T B 77.4/42.7
C19 4030007050 S.CER C1608 CH 1H 220J-T B 80.5/42.7
C20 4030011600 S.CER C1608 JB 1E 104K-T B 74.6/42.7
C21 4030006900 S.CER C1608 JB 1H 103K-T B 71.8/42.7
C25 4030011600 S.CER C1608 JB 1E 104K-T B 110.7/60.9
C26 4510008540 S.ELE EEE1CA100SR B 118.8/65.2
C27 4030011600 S.CER C1608 JB 1E 104K-T B 119/68.3
C34 4030006900 S.CER C1608 JB 1H 103K-T B 62.6/38.7
C35 4030011600 S.CER C1608 JB 1E 104K-T B 66.5/38.7
C37 4030006900 S.CER C1608 JB 1H 103K-T B 49.9/21.6
C38 4030011600 S.CER C1608 JB 1E 104K-T B 47.7/22.3
C39 4030006860 S.CER C1608 JB 1H 102K-T B 44.7/22.3
C40 4030006860 S.CER C1608 JB 1H 102K-T B 42.1/22.3
C41 4030006860 S.CER C1608 JB 1H 102K-T B 39.5/22.3
C42 4030006860 S.CER C1608 JB 1H 102K-T B 36.9/22.3
C44 4030006900 S.CER C1608 JB 1H 103K-T B 58.6/42.4
C46 4030006900 S.CER C1608 JB 1H 103K-T B 29.2/42.8
C47 4030006850 S.CER C1608 JB 1H 471K-T B 23.9/42.8
C48 4030006900 S.CER C1608 JB 1H 103K-T B 33.4/38.2
C49 4030007090 S.CER C1608 CH 1H 470J-T B 26.6/22.5
C50 4030007090 S.CER C1608 CH 1H 470J-T B 22/22.9
C51 4030007130 S.CER C1608 CH 1H 101J-T B 15.1/45.1
C52 4030007130 S.CER C1608 CH 1H 101J-T B 12.9/64.4
C53 4030006900 S.CER C1608 JB 1H 103K-T B 15.2/24.8
C55 4030011600 S.CER C1608 JB 1E 104K-T B 42.2/61.5
C56 4510008540 S.ELE EEE1CA100SR B 46.4/63.5
C57 4030011600 S.CER C1608 JB 1E 104K-T B 64/68.9
C58 4030006900 S.CER C1608 JB 1H 103K-T B 64/67.6
C59 4030006900 S.CER C1608 JB 1H 103K-T B 49.7/66.9
C60 4030006900 S.CER C1608 JB 1H 103K-T B 64/59.4
C61 4550007370 S.TAN F931V225MBABMA B 46.4/69.3
C62 4550007370 S.TAN F931V225MBABMA B 36/84.6
C63 4550007370 S.TAN F931V225MBABMA B 36/81.3
C64 4550007370 S.TAN F931V225MBABMA B 46.4/72.7
C65 4550007650 S.TAN F931V105MAABMA B 43.3/85.2
C66 4550007650 S.TAN F931V105MAABMA B 43.3/83.1
C67 4550007650 S.TAN F931V105MAABMA B 43.3/81
C68 4550007650 S.TAN F931V105MAABMA B 43.3/78.9
C69 4550007650 S.TAN F931V105MAABMA B 43.3/76.8
C71 4030006860 S.CER C1608 JB 1H 102K-T B 45.4/56.7
C72 4510008540 S.ELE EEE1CA100SR B 41.9/54.1
C73 4030006900 S.CER C1608 JB 1H 103K-T B 48.2/56.7
C74 4510008540 S.ELE EEE1CA100SR B 51.7/54.1
C101 4030006860 S.CER C1608 JB 1H 102K-T B 81/73.6
C103 4030006860 S.CER C1608 JB 1H 102K-T B 82.3/73.6
C104 4030007090 S.CER C1608 CH 1H 470J-T B 82.3/84.3
C105 4030007090 S.CER C1608 CH 1H 470J-T B 83.6/73.6
C106 4030007090 S.CER C1608 CH 1H 470J-T B 83.6/84.3
C107 4030007090 S.CER C1608 CH 1H 470J-T B 84.9/73.6
C108 4030006860 S.CER C1608 JB 1H 102K-T B 86.2/73.6
C109 4030006860 S.CER C1608 JB 1H 102K-T B 85.3/84.3
• IC-M604
[REPLACEMENT UNITS]
ORDER NO. UNIT NAME COLOR
0325770121
0325770122
U M604 #21 FRONT
(including LOGIC UNIT)
U M604 #22 FRONT
(including LOGIC UNIT)
BLACK
GRAY
[LOGIC UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1140013650 S.IC HD64F2633RF28 (FX-2577D) B 80/53
IC2 1110005771 S.IC S-80942CNMC-G9CT2G B 88.3/36.4
IC4 1140008650 S.IC HN58X2464TI B 104.6/61
IC5 1180002380 S.IC S-817B33AMC-CWW-T2G B 41.9/59
IC6 1130013200 S.IC TC74LCXR164245 (E F) B 56.4/65.7
IC8 1180000421 S.IC TA78L05F (TE12) B 46.8/53.3
Q4 1530003960 S.TR KTC2875-B-RTK/P B 99.8/42.1
Q12 1590003670 S.TR KRA304-RTK/P B 98.8/73.8
Q13 1590003670 S.TR KRA304-RTK/P B 96.3/73.8
Q15 1530003900 S.TR KTC4075 BL-RTK/P B 113.9/59
Q16 1530003900 S.TR KTC4075 BL-RTK/P B 113.9/61.6
Q17 1520000840 S.TR KTA1664Y-RTF/P B 118.3/60.2
D1 1790001561 S.DIO 1SS372 (TE85) B 94.2/43.1
D3 1730002360 S.ZEN MA8062-M (TX) B 23.5/41.2
D4 1730002360 S.ZEN MA8062-M (TX) B 29.6/41.2
D5 1730002360 S.ZEN MA8062-M (TX) B 33.5/39.9
D6 1750001320 S.DIO KDS4148U RTK/P B 80.3/33.5
X1 6050011090 S.XTL CR-691 (9.8304 MHz) B 75.3/39.4
R4 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 104.7/66.5
R5 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 103.4/66.5
R6 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 96.2/31.9
R7 7030010610 S.RES ERJ1TYJ 470U (47) B 56/53
R8 7030003570 S.RES ERJ3GEYJ 123 V (12 k) B 86.7/40.1
R9 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 85.1/37
R10 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 85.9/35
R12 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 64/66.2
R13 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 64/64.9
R14 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 64/63.6
R15 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 64/62
R16 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 64/60.7
R17 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 102.7/47.6
R18 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 104.1/48.2
R23 7030003570 S.RES ERJ3GEYJ 123 V (12 k) B 110.2/69.8
R24 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k) B 59.9/53.3
R25 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k) B 88.1/66.6
R27 7030003570 S.RES ERJ3GEYJ 123 V (12 k) B 66.7/63.5
R28 7030003570 S.RES ERJ3GEYJ 123 V (12 k) B 66.7/62.2
R29 7030003570 S.RES ERJ3GEYJ 123 V (12 k) B 66.7/60.9
R31 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 98.9/48.5
R32 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 97.6/48.5
R33 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 99.8/45.7
R34 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 99.8/44.4
R35 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 84/41.9
R36 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 100.2/48.5
R37 7030003570 S.RES ERJ3GEYJ 123 V (12 k) B 104.3/73.3
R38 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 46/58.3
R39 7030003330 S.RES ERJ3GEYJ 121 V (120) B 93.6/88.2
R40 7030003330 S.RES ERJ3GEYJ 121 V (120) B 57.7/88.2
R41 7030003630 S.RES ERJ3GEYJ 393 V (39 k) B 110.7/58.3
R42 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 110.7/59.6
R43 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 110.7/62.2
R44 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 114.3/63.5
R45 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 110.7/63.5
R46 7030003360 S.RES ERJ3GEYJ 221 V (220) B 128/51.9
