6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[LOGIC UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C110 4030007090 S.CER C1608 CH 1H 470J-T B 86.6/84.3
C111 4030007090 S.CER C1608 CH 1H 470J-T B 87.5/73.6
C112 4030007090 S.CER C1608 CH 1H 470J-T B 87.9/84.3
C113 4030007090 S.CER C1608 CH 1H 470J-T B 88.8/73.6
C114 4030007090 S.CER C1608 CH 1H 470J-T B 89.2/84.3
C115 4030007090 S.CER C1608 CH 1H 470J-T B 90.1/73.6
C116 4030007090 S.CER C1608 CH 1H 470J-T B 90.5/84.3
C117 4030007090 S.CER C1608 CH 1H 470J-T B 91.4/73.6
C118 4030007090 S.CER C1608 CH 1H 470J-T B 92.7/73.6
C119 4030007090 S.CER C1608 CH 1H 470J-T B 94/73.6
C120 4030007090 S.CER C1608 CH 1H 470J-T B 92.8/84.3
C121 4030006860 S.CER C1608 JB 1H 102K-T B 55/46.7
C124 4030007090 S.CER C1608 CH 1H 470J-T B 45/35.6
C125 4030007090 S.CER C1608 CH 1H 470J-T B 51.3/49.4
C126 4030007090 S.CER C1608 CH 1H 470J-T B 51.3/46.7
C127 4030007090 S.CER C1608 CH 1H 470J-T B 51.2/37.5
C128 4030007090 S.CER C1608 CH 1H 470J-T B 50/46.7
C129 4030007090 S.CER C1608 CH 1H 470J-T B 49.9/37.5
C130 4030007090 S.CER C1608 CH 1H 470J-T B 48.7/46.7
C131 4030007090 S.CER C1608 CH 1H 470J-T B 48.6/37.5
C132 4030007090 S.CER C1608 CH 1H 470J-T B 47.4/46.7
C133 4030007090 S.CER C1608 CH 1H 470J-T B 46.1/46.7
C134 4030007090 S.CER C1608 CH 1H 470J-T B 47.3/37.5
C135 4030007090 S.CER C1608 CH 1H 470J-T B 44.8/46.7
C136 4030007090 S.CER C1608 CH 1H 470J-T B 46/37.5
C137 4030007090 S.CER C1608 CH 1H 470J-T B 43.5/46.7
C138 4030007090 S.CER C1608 CH 1H 470J-T B 44.7/37.5
C139 4030007090 S.CER C1608 CH 1H 470J-T B 42.2/46.7
C140 4030007090 S.CER C1608 CH 1H 470J-T B 43.4/37.5
C141 4030007090 S.CER C1608 CH 1H 470J-T B 40.3/44.6
C142 4030007090 S.CER C1608 CH 1H 470J-T B 42.1/37.5
C143 4030007090 S.CER C1608 CH 1H 470J-T B 57.6/33.7
C151 4030006860 S.CER C1608 JB 1H 102K-T B 37/74.4
C152 4030006860 S.CER C1608 JB 1H 102K-T B 37/71.6
C153 4030006860 S.CER C1608 JB 1H 102K-T B 30/74.4
C154 4030006860 S.CER C1608 JB 1H 102K-T B 30/71.6
J1 6510023361 S.CNR 26FLT-SM2-TB (LF) (SN) B 87.5/78.9
J2 6510023511 S.CNR 28FLT-SM2-TB (LF) (SN) B 49/42
J3 6510023391 S.CNR 27FLZ-SM2-TB (LF) (SN) B 58.6/80.4
J4 6510023261 S.CNR B6B-PH-SM4-TB (LF) (SN) B 23.6/29.2
J5 6510023261 S.CNR B6B-PH-SM4-TB (LF) (SN) B 23.6/37.5
J6 6510022691 S.CNR 06FLT-SM2-TB (LF) (SN) B 33.5/73
J7 6510019421 S.CNR B8B-ZR-SM4-TF (LF) (SN) B 43.9/29.1
DS1 5030002390 LCD HLM7784-010100
DS2 5040002660 S.LED FY1101F-TR (LED) T 88.6/36.7
DS3 5040002660 S.LED FY1101F-TR (LED) T 76.6/36.7
DS4 5040002660 S.LED FY1101F-TR (LED) T 64.6/36.7
DS5 5040002660 S.LED FY1101F-TR (LED) T 52.6/36.7
DS6 5040002660 S.LED FY1101F-TR (LED) T 40.6/36.7
DS7 5040002660 S.LED FY1101F-TR (LED) T 28.6/36.7
DS8 5040002310 S.LED SML-311YTT86 T 106.3/39.8
DS9 5040002310 S.LED SML-311YTT86 T 102.9/27
DS10 5040002310 S.LED SML-311YTT86 T 31.3/27
DS11 5040002310 S.LED SML-311YTT86 T 106.3/77.1
DS12 5040002310 S.LED SML-311YTT86 T 106.3/64.9
DS13 5040002310 S.LED SML-311YTT86 T 106.3/52.7
DS14 5040002310 S.LED SML-311YTT86 T 131.2/39.8
DS15 5040002310 S.LED SML-311YTT86 T 133.1/18.2
DS16 5040002310 S.LED SML-311YTT86 T 107/13.8
DS17 5040002310 S.LED SML-311YTT86 T 131.2/77.1
DS18 5040002310 S.LED SML-311YTT86 T 131.2/64.9
DS19 5040002310 S.LED SML-311YTT86 T 131.2/52.7
DS20 5040002660 S.LED FY1101F-TR (LED) T 28.6/88.2
DS21 5040002660 S.LED FY1101F-TR (LED) T 40.6/88.2
DS22 5040002660 S.LED FY1101F-TR (LED) T 52.6/88.2
DS23 5040002660 S.LED FY1101F-TR (LED) T 64.6/88.2
DS24 5040002660 S.LED FY1101F-TR (LED) T 76.6/88.2
DS25 5040002660 S.LED FY1101F-TR (LED) T 88.6/88.2
S1 2230000250 SW SPPH22014A
[AF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1110002031 IC TA7808S (Q)
IC2 1180000421 S.IC TA78L05F (TE12) T 37.2/31.5
IC3 1110003091 IC LA4425A-E
IC4 1130007690 S.IC BU4066BCF-E2 T 108.2/7.2
IC5 1130007690 S.IC BU4066BCF-E2 T 96.8/7.2
IC6 1110003750 S.IC M5218AFP 600C T 66.1/26.4
IC7 1130007690 S.IC BU4066BCF-E2 T 52.9/26.1
IC8 1110003750 S.IC M5218AFP 600C T 66.1/11.8
IC9 1110003750 S.IC M5218AFP 600C B 146.2/32.7
IC10 1110005801 IC TA8225LQ
IC11 1110004520 S.IC M5222FP 600C B 135.7/36.2
IC12 1170000352 S.IC PC357N6J000F T 86.2/29.1
IC13 1130011120 S.IC BU4584BFV-E2 T 106.8/19
IC14 1110002400 S.IC NJM2107F-TE1 B 127/33.3
IC16 1130007690 S.IC BU4066BCF-E2 T 108.1/35.8
IC17 1130007570 S.IC BU4094BCFV-E2 T 95.7/19
IC18 1130007570 S.IC BU4094BCFV-E2 T 95.7/31.8
IC19 1130007431 S.IC TC7S14FU (TE85) B 88.2/28.2
IC20 1110002400 S.IC NJM2107F-TE1 B 84.6/9.3
Q1 1520000460 S.TR 2SB1132 T100 R T 37.2/39
Q2 1590000430 S.TR DTC144EUA T106 T 42.3/38.6
Q3 1590000430 S.TR DTC144EUA T106 B 40.1/24
Q4 1510000920 S.TR 2SA1577 T106 Q B 28.2/21.8
Q7 1530002551 S.TR 2SC3326-B (TE85) T 32.7/4.5
Q9 1530002851 S.TR 2SC4116-BL (TE85) T 37/9.7
Q11 1530002851 S.TR 2SC4116-BL (TE85) T 80.4/18.6
Q12 1530002851 S.TR 2SC4116-BL (TE85) T 86.4/17.5
Q13 1590001391 S.FET 2SJ144-Y (TE85) B 103.4/19
Q18 1560000811 S.FET 2SK1069-4-TL-E T 51.9/19.1
Q21 1530002851 S.TR 2SC4116-BL (TE85) B 111.3/19.1
Q22 1530002280 S.TR 2SC4081 T106 S B 95.2/25.1
Q23 1590000430 S.TR DTC144EUA T106 B 95.2/21.3
Q24 1560000811 S.FET 2SK1069-4-TL-E T 105.6/24.2
Q25 1530002280 S.TR 2SC4081 T106 S T 108.4/25.8
Q26 1510000510 S.TR 2SA1576A T106R T 111.3/24.6
Q28 1560000811 S.FET 2SK1069-4-TL-E T 102.8/18.4
Q29 1530002280 S.TR 2SC4081 T106 S T 111.2/17.7
Q30 1510000510 S.TR 2SA1576A T106R T 111.1/21.7
Q51 1520000380 TR 2SB1143 S
Q52 1540000550 S.TR 2SD1664 T100Q B 11.8/31.3
Q53 1540000550 S.TR 2SD1664 T100Q B 15.3/26.6
D1 1790000700 DIO DSA3A1
D2 1750000550 S.DIO 1SS355 TE-17 B 20.9/21.6
D5 1160000080 S.DIO DAP202K T146 T 36.1/4.5
D7 1750000550 S.DIO 1SS355 TE-17 T 40.3/10.1
D8 1730002360 S.ZEN MA8062-M (TX) T 126.2/10.4
D11 1750000550 S.DIO 1SS355 TE-17 B 111.1/15.8
D12 1750000550 S.DIO 1SS355 TE-17 B 80.5/30.3
D13 1750000150 S.DIO DA204K T146 B 98.4/26.9
D14 1730002360 S.ZEN MA8062-M (TX) B 95.1/28.6
R1 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 37.2/42.4
R2 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 40.4/38.8
R3 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 37.6/22
R4 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 36.9/19.7
R11 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 37.3/6.8
R12 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 34.5/6.8
R13 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 31.7/6.8
R16 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 24.9/5.5
R17 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 26.2/3.1
R18 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 23.6/5.5
R19 7030000100 S.RES MCR10EZHJ 4.7 (4R7) T 5.8/13
R20 7030003590 S.RES ERJ3GEYJ 183 V (18 k) T 34.8/9.6
R21 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 94.2/37.6
R31 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 75.3/14.3
R32 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 77.5/18
R33 7030003380 S.RES ERJ3GEYJ 331 V (330) T 77.5/16.7
R34 7030003770 S.RES ERJ3GEYJ 564 V (560 k) T 79.5/21.3
R35 7030003710 S.RES ERJ3GEYJ 184 V (180 k) T 77.5/20.6
R36 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) T 80.9/21.3
R37 7030003620 S.RES ERJ3GEYJ 333 V (33 k) T 80.2/16.6
R38 7030003620 S.RES ERJ3GEYJ 333 V (33 k) T 83.4/18.1
R39 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 77.5/21.9
R40 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 83.4/15.5
R41 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 103.2/20.9
R42 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 105.5/15.9
R43 7030003760 S.RES ERJ3GEYJ 474 V (470 k) B 109.7/10.7
R44 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 114.7/9.4
R45 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 112.1/12.4
R46 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 104/2.7
R47 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 110.8/12.4
R48 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 109.5/12.4
R49 7030003280 S.RES ERJ3GEYJ 470 V (47) B 100.8/20.9
R50 7030003280 S.RES ERJ3GEYJ 470 V (47) T 91.8/12.7
R51 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) T 106.2/12.2
R52 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 97.6/2.7
