Icom IC-M604 - IC-M604 Logic, AF, and Connect Unit Parts

7-1 IC-M604
REF. NO. ORDER NO. DESCRIPTION QTY.
W1 8900011440 Cable OPC-1174 1
P1 6510023310 LTWD-06BFFA-L180 1
P2 6510023300 LTWB-03BFFA-L180 1
MC1 Optional product HM-126RB [BLACK] 1
Optional product HM-126RG [GRAY] 1
MP1 8950005110 2289 mic hanger 1
MP2 8610010561 2040 knob bolt-1 [BLACK] 2
8610011260 2040 knob bolt (C)-1 [GRAY] 2
MP3 8010018860 2455 bracket [BLACK] 1
8010020520 2455 bracket (B) [GRAY] 1
MP4 8310050900 2438 warning sticker 1
MP5 8810001490 Screw PH A M5 × 20 SUS 4
MP6 8850000500 Spring washer M5 SUS 4
MP7 8850000180 Flat washer M5 SUS 4
MP8 8810004700 Screw PH A M3 × 16 SUS 2
MP9 8930059480 Sponge (GZ) 2
[ACCESSORIES]
[CHASSIS PARTS]
[MAIN UNIT]
[FRONT UNIT]
[LOGIC UNIT]
[DIAL UNIT]
[VR UNIT]
[SQL UNIT]
[CONNECT UNIT]
Accessories illustation is shown at the next page.
SECTION 7 MECHANICAL PARTS
7 - 1
Screw abbreviations B0, BT: Self-tapping PH: Pan head
FH: Flat head ZK: Black
SUS: Stainless NI: Nickel
NI-ZU: Nickel-Zinc
REF. NO. ORDER NO. DESCRIPTION QTY.
SP1 2510001210 SPEAKER 066P0804 1
W1 8900015550 Cable OPC-1658 1
MP1 8210023090 2577 front panel (C) assembly [BLACK] 1
8210023100 2577 front panel (D) assembly [GRAY] 1
MP12 8610011240 Knob N-295 [BLACK] 1
MP12 8610013010 Knob N-295 (B) [GRAY] 1
MP13 8610011240 Knob N-295 [BLACK] 1
MP13 8610013010 Knob N-295 (B) [GRAY] 1
MP14 8610011210 Knob N-293 [BLACK] 1
MP14 8610013000 Knob N-293 (B) [GRAY] 1
MP17 8930059540 Compression ring R102-P 1
MP18 8810008661 Screw B0 3 × 8 NI-ZC3 (BT) 7
MP19 8930059200 O-ring (AT) 1
MP20 8930053030 2345 earth plate 1
MP21 8850001981 Plain washer M10 10 × 16 × 0.8 ZC3 1
MP22 8930052280 O-ring (AC) 2
MP23 8930058790 2577 SP NET 1
REF. NO. ORDER NO. DESCRIPTION QTY.
J1 6510004880 Antenna connector MR-DSE-01 1
W1 8900015950 Cable OPC-1175A 1
W2 8900011460 Cable OPC-1176 1
W3 8900011161 Cable OPC-1128A 1
W4 8900011811 Cable OPC-1197A-1 1
W5 8900011821 Cable OPC-1198A-1 1
W6 8900011831 Cable OPC-1200A-1 1
MP1 8010020510 2577 A-chassis 1
MP2 8210019050 2577 rear panel assembly [BLACK] 1
8210023130 2577 rear panel (B) assembly [GRAY] 1
MP3 8930058271 2577 F-packing-1 1
MP4 8930058260 2577 R-packing 1
MP5 8930058460 2577 bush plate 1
MP6 8110007800 2577 module cover 1
MP7 8930058480 2577 module plate 1
MP8 8510014900 2577 shield cover 1
MP9 8930034300 1542 ANT seal 1
MP10 8930058780 2577 sheet 1
MP11 8810008661 Screw B0 3 × 8 NI-ZC3 (BT) 7
MP12 8810008661 Screw B0 3 × 8 NI-ZC3 (BT) 3
MP13 8820001210 2438 screw 6
MP14 8820001210 2438 screw 6
MP15 8820001210 2438 screw 2
MP16 8820001210 2438 screw 2
MP17 8810004301 Screw M3 × 10 ZK3 2
MP19 8930052290 O-ring (AD) 8
MP20 8930058450 2577 IC clip 1
MP21 8930058470 2577 IC plate 1
MP22 8930049040 Insulation plate (FQ) 1
MP23 8930055040 2438 cap 5
MP25 8930059021 Thermally sheet (AI)-1 1
MP26 8810008661 Screw B0 3 × 8 NI-ZC3 (BT) 1
REF. NO. ORDER NO. DESCRIPTION QTY.
EP3 6910002161 Shield case-BM7H-LF 1
MP1 8510014870 2577 RX-VCO case 1
MP2 8510014880 2577 TX-VCO case 1
MP3 8510014890 2577 DBM case 1
MP4 8510014890 2577 DBM case 1
MP5 8510015100 2577 shield case 1
MP6 8930059350 2577 earth plate 1
MP9 8930063240 2577 earth spring 1
MP10 8930071140 2577 A-earth plate 1
REF. NO. ORDER NO. DESCRIPTION QTY.
DS1 5030002390 LCD HLM7784-010100 1
S1 2230001170 Switch SPPH220200 1
MP1 8930058440 2577 LCD holder 1
MP2 8210019060 2577 reflector 1
MP3 8930058910 2577 LCD sheet 1
MP4 8930058900 Rubber sheet (BB) 2
REF. NO. ORDER NO. DESCRIPTION QTY.
R1 7210003080 Variable resistor TP96N97-15F-10KA-2345 1
REF. NO. ORDER NO. DESCRIPTION QTY.
R1 7210002360 Variable resistor TP96N97-15F-10KA-1301 1
REF. NO. ORDER NO. DESCRIPTION QTY.
S1 2250000470 Switch EVQ-V9C00116E 1
REF. NO. ORDER NO. DESCRIPTION QTY.
J1 6510022440 Connector LTW-8MP-C 1
J2 6510022440 Connector LTW-8MP-C 1
J3 6510023620 Connector LTWBU-10PMMP-LC 1
[AF UNIT]
REF. NO. ORDER NO. DESCRIPTION QTY.
W6 8900011871 Cable OPC-1203A 1
