6 - 9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1140012070 S.IC µPD789405AGK-B12-9EU B 18.5/25.2
IC2 1110001810 S.IC TA7368F (ER) B 63/17.3
IC3 1110004490 S.IC M62429FP 700C B 46.5/8.9
IC4 1120002830 S.IC NJM2125F-TE1 B 69.8/39.8
IC5 1180000420 S.IC TA78L05F (TE12R) B 42/43.2
IC6 1180001250 S.IC TA7808F (TE16L) B 39.7/24.1
IC7 1110005730 S.IC S-80928CNMC-G8Y-T2 B 36/42.7
IC8 1130007420 S.IC TC7W14FU (TE12L) B 24.7/38.4
IC9 1130006220 S.IC TC4W53FU (TE12L) B 48.5/22.7
Q1 1560000810 S.FET 2SK1069-4-TL B 30/28.9
Q2 1520000460 S.TR 2SB1132 T100 R B 21.2/10.9
Q3 1530002850 S.TR 2SC4116-BL (TE85R) B 31/6.3
Q4 1590001390 S.FET 2SJ144-Y (TE85R) B 45.9/16.4
Q5 1590000430 S.TR DTC144EUA T106 B 59.4/41.9
Q6 1590000980 S.TR DTB123EK T146 B 60.3/45.1
Q9 1560000810 S.FET 2SK1069-4-TL B 29.1/44
Q10 1530002060 S.TR 2SC4081 T106 R B 28.7/38.9
Q11 1510000510 S.TR 2SA1576A T106R B 29.1/41.5
Q12 1530002850 S.TR 2SC4116-BL (TE85R) B 34/6.3
D1 1750000130 S.DIO DA204U T106 B 39.3/6
D2 1160000060 S.DIO DAN202U T106 B 15.3/41
D3 1750000550 S.DIO 1SS355 TE-17 B 55.6/29.4
X1 6060000750 S.CER CSTCC4M91G53-R0) B 26.7/14.9
R1 7030000270 S.RES MCR10EZHJ 120 (121) B 3.4/19.7
R2 7030000270 S.RES MCR10EZHJ 120 (121) B 3.5/30.9
R3 7030000280 S.RES MCR10EZHJ 150 (151) B 56.9/39
R6 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 12.2/14.8
R7 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 14.1/14.6
R8 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 12.2/13.5
R9 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 10.3/13.1
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 10.8/36.4
R11 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 12.1/39.5
R12 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 12.6/35.9
R13 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 13.9/35.6
R14 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 13.4/39.5
R15 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 17.2/40.2
R16 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 18.8/40.4
R17 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 18/42.3
R18 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 26.8/32.8
R19 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 23.8/15.5
R20 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 32.7/29.7
R21 7030003630 S.RES ERJ3GEYJ 393 V (39 k) B 34.5/27.8
R22 7030004120 S.RES ERJ3GEYJ 203 V (20 k) B 33.2/27.8
R23 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 31.9/27.8
R24 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k) B 28.1/30.6
R25 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 30.2/30.9
R26 7510001671 S.TMR NTCG16 4BH 103JT B 33.1/32.3
R27 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 33.1/31
R28 7030004120 S.RES ERJ3GEYJ 203 V (20 k) B 25.8/10.4
R29 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 27.7/9.8
R30 7030003590 S.RES ERJ3GEYJ 183 V (18 k) B 25.8/9.1
R31 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 27.7/7.1
R32 7030004120 S.RES ERJ3GEYJ 203 V (20 k) B 25.8/7.8
R33 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 25.8/6.5
R34 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 34.2/8.2
R35 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) B 51.8/10.6
R36 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 51.1/14.4
R37 7030003600 S.RES ERJ3GEYJ 223 V (22 k) B 48.7/12.4
R38 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 41.5/6.7
R39 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 48.6/15.6
R40 7030003760 S.RES ERJ3GEYJ 474 V (470 k) B 48.6/16.9
R41 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 48.6/19.5
R42 7030003570 S.RES ERJ3GEYJ 123 V (12 k) T 79.1/44.7
R43 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) T 72.4/39.3
R44 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 68.4/42.2
R45 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 71.1/42.2
R46 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 71.9/36.9
R47 7030003730 S.RES ERJ3GEYJ 274 V (270 k) B 69.8/36.1
R50 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 33.4/43.1
R51 7030003610 S.RES ERJ3GEYJ 273 V (27 k) B 34.4/45.8
R52 7030003630 S.RES ERJ3GEYJ 393 V (39 k) B 35.8/40.3
R53 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 26.6/34.7
R54 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 26.1/42.2
R55 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 29.4/45.9
R56 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 31.1/43.5
R57 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 26.3/40.8
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R58 7030003280 S.RES ERJ3GEYJ 470 V (47) B 31.6/40.3
R59 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 29.8/8.2
R60 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 29/10.1
R61 7030003630 S.RES ERJ3GEYJ 393 V (39 k) B 29/6.3
R62 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 26.6/5.2
R63 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 31.1/4.4
R64 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k) B 33.9/4.4
R65 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 45.5/25.1
R66 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 46.3/26.4
R67 7030003800 S.RES ERJ3GEYJ 105 V (1 M) B 49/26.4
R68 7030003320 S.RES ERJ3GEYJ 101 V (100) B 58.1/29
R69 7030003320 S.RES ERJ3GEYJ 101 V (100) B 15.3/39
R70 7030003260 S.RES ERJ3GEYJ 330 V (33) B 43.7/4.6
R75 7030000180 S.RES MCR10EZHJ 22 (220) B 55.1/14.9
R76 7030000180 S.RES MCR10EZHJ 22 (220) B 55.1/13.1
R77 7030000180 S.RES MCR10EZHJ 22 (220) B 55.2/10.6
C1 4510004630 S.ELE ECEV1CA100SR B 15.8/10.6
C3 4510005430 S.ELE ECEV0JA220SR B 10.3/8.8
C4 4030006900 S.CER C1608 JB 1H 103K-T B 9/13.1
C5 4030006900 S.CER C1608 JB 1H 103K-T B 18/43.6
C6 4030006900 S.CER C1608 JB 1H 103K-T B 31.2/32.8
C7 4030011600 S.CER C1608 JB 1E 104K-T B 28.9/32.6
C9 4030006900 S.CER C1608 JB 1H 103K-T B 14.4/7.5
C10 4030017480 S.CER C1608 JB 1A 474K-T B 51.8/9.3
C11 4030011600 S.CER C1608 JB 1E 104K-T B 46/12.4
C12 4030012600 S.CER C2012 JB 1A 105M-T B 51.7/12.2
C13 4030006900 S.CER C1608 JB 1H 103K-T B 52.4/14.4
C14 4030011600 S.CER C1608 JB 1E 104K-T B 57.7/14.7
C15 4510006220 S.ELE ECEV1CA101UP B 59.7/9.7
C16 4510006220 S.ELE ECEV1CA101UP B 54.8/19.4
C17 4510006220 S.ELE ECEV1CA101UP B 62.7/23.8
C18 4510006250 S.ELE ECEV1CA331UP B 68.6/9.1
C22 4030006900 S.CER C1608 JB 1H 103K-T B 41.8/9.5
C23 4510005430 S.ELE ECEV0JA220SR B 47.4/3.7
C24 4030012600 S.CER C2012 JB 1A 105M-T B 48.3/14
C25 4030006900 S.CER C1608 JB 1H 103K-T B 48.6/18.2
C26 4030012600 S.CER C2012 JB 1A 105M-T B 45.9/19.5
C27 4030006850 S.CER C1608 JB 1H 471K-T B 79.1/44.3
C28 4030011600 S.CER C1608 JB 1E 104K-T B 65.4/39.1
C29 4030006860 S.CER C1608 JB 1H 102K-T B 66.7/39.8
C30 4510004630 S.ELE ECEV1CA100SR B 69.5/45.4
C31 4030011810 S.CER C1608 JB 1A 224K-T B 73.2/36.9
C32 4030007090 S.CER C1608 CH 1H 470J-T B 69.8/37.4
C33 4030012600 S.CER C2012 JB 1A 105M-T B 66.6/37
C34 4030011600 S.CER C1608 JB 1E 104K-T B 45.2/40.9
C35 4510005430 S.ELE ECEV0JA220SR B 61.8/38.1
C36 4030011600 S.CER C1608 JB 1E 104K-T B 41.2/39.8
C37 4510005430 S.ELE ECEV0JA220SR B 46.9/44.8
C38 4030011600 S.CER C1608 JB 1E 104K-T B 38.6/9.2
C39 4510006220 S.ELE ECEV1CA101UP B 32.3/19
C40 4030011600 S.CER C1608 JB 1E 104K-T B 41.1/36.5
C41 4510006250 S.ELE ECEV1CA331UP B 49.2/35.1
C42 4030008890 S.CER C1608 JB 1H 273K-T B 38.5/42.5
C44 4030011600 S.CER C1608 JB 1E 104K-T B 29.3/33.9
C45 4030006900 S.CER C1608 JB 1H 103K-T B 25.6/36
C46 4030011600 S.CER C1608 JB 1E 104K-T B 27.1/44.3
C47 4030006850 S.CER C1608 JB 1H 471K-T B 51.1/25.5
C50 4030006860 S.CER C1608 JB 1H 102K-T B 71.1/28.4
C51 4030007090 S.CER C1608 CH 1H 470J-T B 61.4/28.3
C52 4030007090 S.CER C1608 CH 1H 470J-T B 55.6/31
C53 4030006900 S.CER C1608 JB 1H 103K-T B 48.4/25.1
C54 4030012600 S.CER C2012 JB 1A 105M-T B 52.7/25.3
J1 6510019420 S.CNR B8B-ZR-SM3-TF B 64.9/33.3
DS1 5030001900 LCD A0119 LCD36*28.5
DS2 5040002660 S.LED FY1101F-TR (LED) T 27.7/4.2
DS3 5040002660 S.LED FY1101F-TR (LED) T 15.7/4.2
DS4 5040002310 S.LED SML-311YTT86 T 5.9/18.4
DS5 5040002660 S.LED FY1101F-TR (LED) T 27.7/46.2
DS6 5040002660 S.LED FY1101F-TR (LED) T 15.7/46.2
DS7 5040002310 S.LED SML-311YTT86 T .9/32
DS8 5040002310 S.LED SML-311YTT86 T 45.8/18.2
DS9 5040002310 S.LED SML-311YTT86 T 65.7/18.2
DS10 5040002310 S.LED SML-311YTT86 T 53.8/36.2
MC1 7700002480 MIC SKB-2746 LPC
S1 2260002710 S.SW SKQLLCE012 B 3/14.2
S2 2260002710 S.SW SKQLLCE012 B 3/25.2
S3 2260002710 S.SW SKQLLCE012 B 3/36.2
S4 2260002800 S.SW SW-167 (SKQTLAE010) B 20.7/2.7
EP2 8930051120 LCT SRCN-2320-SP-N-W
• HM-126RB/RG
[REPLACEMENT UNITS]
ORDER NO. UNIT NAME COLOR
Optional product
Optional product
HM-126RB [USA]
HM-126RG [USA-01]
BLACK
GRAY
