6 - 8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
J3 6510007020 CNR TMP-J01X-V6
W7 7030010840 S.JMP MJP-0.2-T T 72.7/50.9
W12 7030010860 JMP MJP-0.6
EP2 6910013370 S.BEA BLM18BB221SN1D T 71.2/21
EP3 6910002161 CAS CASE-BM7H-LF
[CONNECT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q1 1590003560 S.FET TPC6104 (TE85L F) T 44.2/3
Q2 1590003580 S.TR KRC404 RTK/P T 62.7/24.9
Q3 1590003560 S.FET TPC6104 (TE85L F) T 49.3/8.2
Q4 1590003580 S.TR KRC404 RTK/P T 76.6/18.3
D1 1730002360 S.ZEN MA8062-M (TX) T 64.4/19.1
D2 1730002360 S.ZEN MA8062-M (TX) T 75.5/16.1
R1 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 46.7/4.4
R2 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 48/4.4
R3 7030003320 S.RES ERJ3GEYJ 101 V (100) T 51.4/12.3
R4 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 46.9/8.6
R5 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 51.4/11
R6 7030003320 S.RES ERJ3GEYJ 101 V (100) T 74.7/13.7
C1 4030006860 S.CER C1608 JB 1H 102K-T T 46.8/21.2
C2 4030006860 S.CER C1608 JB 1H 102K-T T 46.8/19.9
C8 4030006860 S.CER C1608 JB 1H 102K-T T 18.8/19
C9 4030006860 S.CER C1608 JB 1H 102K-T T 6.3/19.6
C11 4030006860 S.CER C1608 JB 1H 102K-T T 35.4/5
C13 4030006860 S.CER C1608 JB 1H 102K-T T 34.6/11.9
C16 4030006860 S.CER C1608 JB 1H 102K-T T 44.9/6.8
C17 4030006860 S.CER C1608 JB 1H 102K-T T 40.2/4.7
C18 4030006860 S.CER C1608 JB 1H 102K-T T 48.5/11.9
C21 4030006860 S.CER C1608 JB 1H 102K-T T 68.1/4.5
C23 4030006860 S.CER C1608 JB 1H 102K-T T 63/13.1
C26 4030006860 S.CER C1608 JB 1H 102K-T T 74.1/7.6
C27 4030006860 S.CER C1608 JB 1H 102K-T T 69.9/4.5
C28 4030006860 S.CER C1608 JB 1H 102K-T T 74.3/11.5
C31 4030006860 S.CER C1608 JB 1H 102K-T T 60.5/24.9
C32 4030006860 S.CER C1608 JB 1H 102K-T T 66.3/16.1
C35 4030006860 S.CER C1608 JB 1H 102K-T T 76.5/20.2
C36 4030011600 S.CER C1608 JB 1E 104K-T T 76/13.7
J1 6510022440 CNR LTW-8MP-C NUT,GASKET
J2 6510022440 CNR LTW-8MP-C NUT,GASKET
J3 6510023320 CNR LTWD-06PMMP-LC <LIA>
J4 6510023091 S.CNR 20FLT-SM2-TB (LF) (SN) T 54.5/20
J5 6510014961 S.CNR B2B-ZR-SM4-TF (LF) (SN) T 12.9/21.3
J6 6510022691 S.CNR 06FLT-SM2-TB (LF) (SN) T 70/19.7
J6 6510025820 S.CNR 06FLZT-SM1-TF (H) (LF)(SN) T 70/19.7
F1 5210001000 S.FUS ERBSE2R50U T 37.4/3.7
F2 5210001000 S.FUS ERBSE2R50U T 62.5/5.6
W1 8900015560 CBL OPC-1659 (P0.5,N6,L140)
[DIAL UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
S1 2250000470 ECR EVQ-V9C00116E
W1 8900011721 CBL OPC-1187A
[VR UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R1 7210003080 VAR TP96N97-15F-10KA-2345
W1 8900015960 CBL OPC-1186A
[SQL UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R1 7210002360 VAR TP96N97-15F-10KB-1301
To Next Page
