6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[AF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R53 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 91.3/2.8
R54 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 113.4/10.5
R55 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 102/3.5
R56 7030003280 S.RES ERJ3GEYJ 470 V (47) T 91.4/10.8
R57 7030003760 S.RES ERJ3GEYJ 474 V (470 k) T 89.7/2.8
R59 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 85.8/3.5
R60 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 87.9/2.8
R61 7030003280 S.RES ERJ3GEYJ 470 V (47) T 61.4/28.2
R62 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 70.3/24.1
R63 7030003580 S.RES ERJ3GEYJ 153 V (15 k) T 70.3/25.4
R64 7030003650 S.RES ERJ3GEYJ 563 V (56 k) T 70.3/26.7
R67 7030003590 S.RES ERJ3GEYJ 183 V (18 k) T 69.5/28.7
R68 7030003590 S.RES ERJ3GEYJ 183 V (18 k) T 68.9/31.1
R69 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 66.1/31.1
R71 7030003280 S.RES ERJ3GEYJ 470 V (47) T 51.2/21.3
R72 7030003590 S.RES ERJ3GEYJ 183 V (18 k) T 62.7/25.3
R73 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 66.2/20.3
R74 7030003760 S.RES ERJ3GEYJ 474 V (470 k) T 63.4/21.6
R75 7030003590 S.RES ERJ3GEYJ 183 V (18 k) T 60.3/24.7
R76 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 60.3/26
R79 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 52.7/32.5
R80 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 54.4/32.5
R81 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 58.2/29
R82 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 47.6/23.9
R83 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 61.4/17.5
R84 7030003670 S.RES ERJ3GEYJ 823 V (82 k) T 62.7/14.6
R85 7030003570 S.RES ERJ3GEYJ 123 V (12 k) T 64.9/16.9
R86 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 67.7/17.9
R87 7030003690 S.RES ERJ3GEYJ 124 V (120 k) T 60.1/11.8
R88 7030003690 S.RES ERJ3GEYJ 124 V (120 k) T 58.8/11.8
R89 7030003660 S.RES ERJ3GEYJ 683 V (68 k) T 61.4/9
R89 7030003670 S.RES ERJ3GEYJ 823 V (82 k) T 61.4/9
R90 7030003660 S.RES ERJ3GEYJ 683 V (68 k) T 62.7/9
R91 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 64.8/5.5
R92 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 60.1/6.2
R94 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 57/17.1
R95 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 55.1/17.7
R96 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k) T 53.8/18.4
R97 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 58.8/33.6
R197 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) B 142.2/36.5
R198 7030003590 S.RES ERJ3GEYJ 183 V (18 k) B 148.4/38.8
R199 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 148.4/37.5
R201 7030003590 S.RES ERJ3GEYJ 183 V (18 k) B 141/31
R202 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 149.8/27.8
R203 7030003790 S.RES ERJ3GEYJ 824 V (820 k) B 145.4/36.2
R204 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 140.6/37.4
R205 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 129.7/37.2
R206 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 137.2/32.7
R207 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 130.2/30.8
R208 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 133.3/31.4
R209 7030003610 S.RES ERJ3GEYJ 273 V (27 k) B 135.7/29.3
R210 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 136.5/31.4
R211 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 117.2/41
R212 7030003300 S.RES ERJ3GEYJ 680 V (68) B 153.3/35.4
R213 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 151.2/35
R214 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) B 152.6/30.8
R215 7030003300 S.RES ERJ3GEYJ 680 V (68) B 153.3/33.1
R216 7030000020 S.RES MCR10EZHJ 1 (010) B 152.2/22.3
R217 7030000020 S.RES MCR10EZHJ 1 (010) B 153.8/28.5
R218 7030003620 S.RES ERJ3GEYJ 333 V (33 k) B 154.4/38.2
R219 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 112.9/21.4
R221 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 90.5/27.9
R222 7030003400 S.RES ERJ3GEYJ 471 V (470) B 83.6/32.3
R223 7030003640 S.RES ERJ3GEYJ 473 V (47 k) B 98.2/21.6
R224 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 95.4/27
R225 7030003210 S.RES ERJ3GEYJ 120 V (12) B 98.2/24.6
R226 7030003680 S.RES ERJ3GEYJ 104 V (100 k) B 94.6/30.2
R230 7030003200 S.RES ERJ3GEYJ 100 V (10) B 108/22.5
R231 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 102.6/24.4
R232 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 102.6/23.1
R233 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 102.6/21.8
R244 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 108.6/23.6
R245 7030003280 S.RES ERJ3GEYJ 470 V (47) T 111.3/26.7
R260 7030003200 S.RES ERJ3GEYJ 100 V (10) B 108/19.7
R261 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 100.5/20.3
R262 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 102.6/20.5
R263 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 102.6/16.2
R264 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 111.6/15.8
R265 7030003280 S.RES ERJ3GEYJ 470 V (47) T 111.3/19.8
R267 7030003280 S.RES ERJ3GEYJ 470 V (47) T 100/37.9
R268 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 102.1/33.4
R269 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 108.1/27.9
R270 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 104.7/29.2
R271 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 108.6/40.1
R272 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 105.5/31.1
R273 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 110.2/30.4
R274 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) T 111.6/30.4
R275 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 113.4/39.9
R276 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 114.5/35.1
R277 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) T 114.5/33.8
R301 7030003400 S.RES ERJ3GEYJ 471 V (470) B 16.6/32.8
S.=Surface mount
[AF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R302 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) B 7.2/30.5
R303 7030009591 S.RES ERA3YED 472V (4.7 k) B 7.2/27.5
R304 7030009591 S.RES ERA3YED 472V (4.7 k) B 6.4/25.3
R305 7030000190 S.RES MCR10EZHJ 27 (270) B 5.1/39.1
R306 7030000190 S.RES MCR10EZHJ 27 (270) B 6.2/36.9
R307 7030000190 S.RES MCR10EZHJ 27 (270) B 7.3/34.7
R308 7030000190 S.RES MCR10EZHJ 27 (270) B 10.6/20.6
R309 7030000190 S.RES MCR10EZHJ 27 (270) B 8.4/22.6
R310 7030000190 S.RES MCR10EZHJ 27 (270) B 10.6/25.5
R311 7030000190 S.RES MCR10EZHJ 27 (270) B 16.9/30.1
R312 7030000190 S.RES MCR10EZHJ 27 (270) B 19.8/30.1
R313 7030000190 S.RES MCR10EZHJ 27 (270) B 22/31.2
R314 7030003400 S.RES ERJ3GEYJ 471 V (470) T 20.2/16.7
R315 7030003400 S.RES ERJ3GEYJ 471 V (470) T 18.9/16.7
R316 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 89.7/5.8
R317 7030003620 S.RES ERJ3GEYJ 333 V (33 k) T 90.7/8.3
R318 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 90.1/10.8
R323 7030003860 S.RES ERJ3GE JPW V B 145.4/39.1
C1 4030007090 S.CER C1608 CH 1H 470J-T T 14.9/38.4
C2 4030006860 S.CER C1608 JB 1H 102K-T T 14.9/37.1
C3 4030007090 S.CER C1608 CH 1H 470J-T T 14.9/35.8
C4 4030006900 S.CER C1608 JB 1H 103K-T T 17.6/34.2
C5 4030006850 S.CER C1608 JB 1H 471K-T T 24.8/34.2
C6 4030006860 S.CER C1608 JB 1H 102K-T T 9.6/33.4
C7 4030007090 S.CER C1608 CH 1H 470J-T T 9.6/32.1
C8 4030006860 S.CER C1608 JB 1H 102K-T T 19.8/27.2
C9 4030007090 S.CER C1608 CH 1H 470J-T T 21.1/27.2
C10 4510007480 ELE 16 ME 470 CA+TS
C11 4030007090 S.CER C1608 CH 1H 470J-T T 70.5/10.7
C12 4030006900 S.CER C1608 JB 1H 103K-T T 70.5/9.4
C18 4030006850 S.CER C1608 JB 1H 471K-T T 35.9/34.8
C19 4030006850 S.CER C1608 JB 1H 471K-T T 38.6/34.8
C21 4510008540 S.ELE EEE1CA100SR T 9.1/23
C22 4030011600 S.CER C1608 JB 1E 104K-T T 5.5/23.8
C23 4510008540 S.ELE EEE1CA100SR T 17.9/21
C24 4030011600 S.CER C1608 JB 1E 104K-T T 14.9/23.4
C25 4030006900 S.CER C1608 JB 1H 103K-T T 40.9/35.9
C26 4510008540 S.ELE EEE1CA100SR T 42.3/32.2
C27 4030006860 S.CER C1608 JB 1H 102K-T T 44.2/37.2
C28 4030007090 S.CER C1608 CH 1H 470J-T B 3.2/16.7
C29 4030007090 S.CER C1608 CH 1H 470J-T B 4.8/15.1
C30 4030007090 S.CER C1608 CH 1H 470J-T B 3.2/13.6
C31 4030017490 S.CER C1608 JB 1A 105K-T T 29.4/3.1
C32 4030006900 S.CER C1608 JB 1H 103K-T T 26.9/6.2
C33 4030017490 S.CER C1608 JB 1A 105K-T T 23/3.1
C34 4030006850 S.CER C1608 JB 1H 471K-T T 4.4/10.8
C35 4030011600 S.CER C1608 JB 1E 104K-T T 3.7/17.9
C36 4510004591 ELE 16 ME 470 HC+TS
C37 4510004591 ELE 16 ME 470 HC+TS
C38 4030011600 S.CER C1608 JB 1E 104K-T T 5.4/14.6
C39 4030006850 S.CER C1608 JB 1H 471K-T T 21.5/16.7
C40 4030007090 S.CER C1608 CH 1H 470J-T T 3.4/13.6
C41 4550000530 S.TAN TEESVA 1V 104M8R T 78.8/14.9
C42 4030008890 S.CER C1608 JB 1H 273K-T T 75.3/17.1
C43 4030008890 S.CER C1608 JB 1H 273K-T T 77.5/19.3
C44 4030006870 S.CER C1608 JB 1H 222K-T T 83.4/16.8
C45 4030010040 S.CER C1608 JB 1H 561K-T T 84.8/19.4
C46 4510008540 S.ELE EEE1CA100SR T 84.8/22.5
C47 4030017490 S.CER C1608 JB 1A 105K-T T 86.6/15.4
C48 4030017490 S.CER C1608 JB 1A 105K-T B 107.8/11.8
C49 4030010770 S.CER C1608 JB 1H 392K-T B 105.5/17.2
C50 4030017490 S.CER C1608 JB 1A 105K-T B 98/18.9
C51 4030017490 S.CER C1608 JB 1A 105K-T T 116.3/9.8
C52 4030006870 S.CER C1608 JB 1H 222K-T T 131.2/11.7
C53 4030006850 S.CER C1608 JB 1H 471K-T T 124.5/10.7
C55 4030011600 S.CER C1608 JB 1E 104K-T T 102.9/9.3
C56 4030011600 S.CER C1608 JB 1E 104K-T T 108.2/12.4
C58 4030006900 S.CER C1608 JB 1H 103K-T T 92.3/14.5
C59 4030011600 S.CER C1608 JB 1E 104K-T T 104.2/12.4
C60 4030006900 S.CER C1608 JB 1H 103K-T T 88.8/11.4
C61 4030017490 S.CER C1608 JB 1A 105K-T T 91.3/5.9
C63 4030011600 S.CER C1608 JB 1E 104K-T T 87.5/11.4
C64 4030017490 S.CER C1608 JB 1A 105K-T T 94.1/2.3
C71 4030006860 S.CER C1608 JB 1H 102K-T T 62.7/28.2
C72 4510008540 S.ELE EEE1CA100SR T 71.7/21
C73 4030011600 S.CER C1608 JB 1E 104K-T T 68.2/20.9
C75 4030011810 S.CER C1608 JB 1A 224K-T T 71.7/31.1
C76 4030007090 S.CER C1608 CH 1H 470J-T T 66.1/32.4
C77 4030006870 S.CER C1608 JB 1H 222K-T T 66.2/21.6
C78 4030007020 S.CER C1608 CH 1H 120J-T T 63.4/20.3
C79 4030011600 S.CER C1608 JB 1E 104K-T T 62.7/31
C80 4030006900 S.CER C1608 JB 1H 103K-T T 61.4/31
C81 4030011600 S.CER C1608 JB 1E 104K-T T 47.6/28.6
C82 4030011600 S.CER C1608 JB 1E 104K-T T 48.7/20
C83 4030011600 S.CER C1608 JB 1E 104K-T T 62.7/17.5
C84 4030007050 S.CER C1608 CH 1H 220J-T T 67.7/16.6
C85 4030006860 S.CER C1608 JB 1H 102K-T T 61.4/11.8
C86 4030010770 S.CER C1608 JB 1H 392K-T T 64.8/6.9
C87 4030007120 S.CER C1608 CH 1H 820J-T T 62.7/11.8
