6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[AF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C89 4030008900 S.CER C1608 JB 1H 333K-T T 61.4/6.2
C90 4030006900 S.CER C1608 JB 1H 103K-T T 68.1/6.2
C91 4030011600 S.CER C1608 JB 1E 104K-T T 66.8/6.2
C92 4030006900 S.CER C1608 JB 1H 103K-T T 60.1/14.6
C93 4030011600 S.CER C1608 JB 1E 104K-T T 61.4/14.6
C94 4510008540 S.ELE EEE1CA100SR T 49.5/14.3
C95 4030011600 S.CER C1608 JB 1E 104K-T T 50/19.3
C96 4030011600 S.CER C1608 JB 1E 104K-T T 51.4/32.5
C97 4030011600 S.CER C1608 JB 1E 104K-T T 65.1/38.9
C98 4030011600 S.CER C1608 JB 1E 104K-T T 101.4/29.4
C200 4510009060 S.ELE EEE1HA3R3SR T 122.2/28.3
C201 4030011600 S.CER C1608 JB 1E 104K-T B 129.7/38.5
C202 4030011600 S.CER C1608 JB 1E 104K-T B 146.8/29.3
C204 4030017490 S.CER C1608 JB 1A 105K-T B 139.1/30.2
C205 4030011600 S.CER C1608 JB 1E 104K-T B 132.5/29.3
C206 4510009060 S.ELE EEE1HA3R3SR T 142.8/38
C207 4510004601 ELE 16 ME 1000 HC+T0
C208 4030006900 S.CER C1608 JB 1H 103K-T B 149.8/25.1
C209 4510008500 S.ELE EEE1CA101WP T 150.1/38.6
C210 4510008500 S.ELE EEE1CA101WP T 150.1/31.3
C211 4510008520 S.ELE EEE1CA470SP T 141.2/31.3
C212 4510008830 S.ELE EEE1CA221P T 148.3/23.1
C213 4510008830 S.ELE EEE1CA221P T 148.3/13.9
C214 4030006860 S.CER C1608 JB 1H 102K-T B 152.6/24.6
C215 4030008920 S.CER C1608 JB 1H 473K-T B 154.8/30.8
C216 4030008920 S.CER C1608 JB 1H 473K-T B 153.3/20.2
C217 4030006860 S.CER C1608 JB 1H 102K-T B 155.8/38.2
C219 4030011600 S.CER C1608 JB 1E 104K-T B 133.3/32.7
C220 4030011600 S.CER C1608 JB 1E 104K-T B 88.9/32.3
C221 4030006900 S.CER C1608 JB 1H 103K-T B 87/30.5
C222 4030006880 S.CER C1608 JB 1H 472K-T B 82.1/29.9
C225 4030006900 S.CER C1608 JB 1H 103K-T B 94.6/23.2
C227 4030006900 S.CER C1608 JB 1H 103K-T T 76.1/38.8
C228 4030006860 S.CER C1608 JB 1H 102K-T T 72.8/33.8
C229 4030006900 S.CER C1608 JB 1H 103K-T T 133.7/27.1
C237 4030006900 S.CER C1608 JB 1H 103K-T B 105.8/24.3
C251 4030006900 S.CER C1608 JB 1H 103K-T B 106.2/19.7
C254 4030006900 S.CER C1608 JB 1H 103K-T T 101.3/37.9
C260 4030017490 S.CER C1608 JB 1A 105K-T T 107.8/29.5
C261 4030017490 S.CER C1608 JB 1A 105K-T T 115/39.5
C262 4030017490 S.CER C1608 JB 1A 105K-T T 101.9/31.8
C263 4030006860 S.CER C1608 JB 1H 102K-T T 99.8/29.2
C265 4030006860 S.CER C1608 JB 1H 102K-T T 102.7/29
C266 4030011600 S.CER C1608 JB 1E 104K-T T 92.4/22.3
C267 4030011600 S.CER C1608 JB 1E 104K-T T 92.9/37.6
C270 4030007090 S.CER C1608 CH 1H 470J-T T 10.3/7.6
C271 4030006860 S.CER C1608 JB 1H 102K-T T 12.3/11
C272 4030006860 S.CER C1608 JB 1H 102K-T B 12.9/10.5
C273 4030006860 S.CER C1608 JB 1H 102K-T T 120.5/2.3
C274 4030006860 S.CER C1608 JB 1H 102K-T T 123.2/10
C275 4030006860 S.CER C1608 JB 1H 102K-T T 39.6/5.3
C276 4030006860 S.CER C1608 JB 1H 102K-T T 39.4/8
C277 4030006860 S.CER C1608 JB 1H 102K-T T 43/3.6
C278 4030006860 S.CER C1608 JB 1H 102K-T T 46.2/3.3
C279 4030006850 S.CER C1608 JB 1H 471K-T T 56.3/4.2
C281 4030006850 S.CER C1608 JB 1H 471K-T T 47.7/10.8
C282 4030011810 S.CER C1608 JB 1A 224K-T T 108.2/31.1
C283 4030011810 S.CER C1608 JB 1A 224K-T T 113.4/37.1
C301 4510008540 S.ELE EEE1CA100SR T 30.3/40.5
RL1 6330001670 RLY FTR-P3CP012W1
RL2 6330001620 RLY FTR-F3AA012E
RL3 6330001460 RLY FTR-F1CA012V
J1 6510023511 S.CNR 28FLT-SM2-TB (LF) (SN) T 80/7.2
J2 6510022621 S.CNR 10FMN-BMTTR-A-TBT (LF) (SN) T 46.5/7.1
J3 6510016431 S.CNR 53307-1471 T 60.3/37.4
J4 6510023091 S.CNR 20FLT-SM2-TB (LF) (SN) T 80/34
J5 6510023421 CNR SB4P-HVQ-A (LF) (SN)
J6 6510019371 S.CNR B3B-ZR-SM4-TF (LF) (SN) T 120.2/5.4
J7 6510018961 S.CNR B2B-PH-SM4-TB (LF) (SN) T 130.6/5.6
J8 6510003381 CNR B02B-EH-S (LF) (SN)
J9 6510020800 CNR OP-10
J10 6510020800 CNR OP-10
J11 6510018961 S.CNR B2B-PH-SM4-TB (LF) (SN) T 140/5.6
W6 8900011871 CBL OPC-1203A
EP2 6910013370 S.BEA BLM18BB221SN1D T 117.8/2.3
EP3 6910013370 S.BEA BLM18BB221SN1D T 121/10.7
EP4 6910018270 S.BEA MMZ1608Y301CT T 6.4/10.2
EP5 6910018270 S.BEA MMZ1608Y301CT T 100.7/27.2
EP6 6910018270 S.BEA MMZ1608Y301CT T 70.8/28.7
EP7 6910014690 S.BEA MPZ1608S221A-T B 15.1/16.5
EP8 6910018270 S.BEA MMZ1608Y301CT T 128.5/11.7
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1110003491 S.IC TA31136FNG (D EL) T 113.7/6.5
IC2 1120002830 S.IC NJM2125F-TE1 T 147.9/9.3
IC3 1110003780 S.IC NJM2902V-TE1 T 151.4/38.7
IC5 1130011120 S.IC BU4584BFV-E2 T 151.8/22.9
IC6 1110003491 S.IC TA31136FNG (D EL) T 114.9/37.1
IC9 1110003650 S.IC NJM2211M-TE1 B 149.7/44.6
IC11 1130005641 S.IC TC4W53F (TE12L F) B 153.1/16.3
IC12 1130007611 S.IC µPD3140GS-E1-A T 117.4/23.6
IC13 1150002082 IC RA35H1516M-121
IC14 1110002400 S.IC NJM2107F-TE1 T 72.8/43.1
IC15 1190000350 S.IC M62363FP-650C T 138.5/20.9
Q1 1580000751 S.FET 3SK294 (TE85L F) T 7.3/24.9
Q2 1530002601 S.TR 2SC4215-O (TE85) B 101.6/4.1
Q3 1560000990 S.FET PMBFJ310 B 71.4/3.3
Q4 1560000990 S.FET PMBFJ310 B 71.4/9.1
Q7 1580000751 S.FET 3SK294 (TE85L F) T 19.2/27.8
Q8 1560000990 S.FET PMBFJ310 B 72.1/28.4
Q9 1560000990 S.FET PMBFJ310 B 70.2/23.3
Q10 1530002601 S.TR 2SC4215-O (TE85) B 99.5/23.4
Q11 1530002851 S.TR 2SC4116-BL (TE85) T 98.7/16.8
Q12 1560000990 S.FET PMBFJ310 T 94.1/13.4
Q13 1530002601 S.TR 2SC4215-O (TE85) T 82.1/12.5
Q14 1530002601 S.TR 2SC4215-O (TE85) B 79.8/9
Q15 1530002601 S.TR 2SC4215-O (TE85) B 86.2/38.5
Q16 1530002851 S.TR 2SC4116-BL (TE85) T 124.7/14.8
Q17 1530002851 S.TR 2SC4116-BL (TE85) T 84.1/34.9
Q18 1560000990 S.FET PMBFJ310 T 92.4/32.7
Q19 1530002601 S.TR 2SC4215-O (TE85) T 89.6/36.1
Q21 1590000720 S.TR DTA144EUA T106 T 115.1/31.7
Q22 1590000430 S.TR DTC144EUA T106 T 118.1/32.1
Q23 1530003421 S.TR 2SC5110-O (TE85) T 70.2/15.4
Q27 1530003421 S.TR 2SC5110-O (TE85) T 72.8/33.2
Q28 1530002241 S.TR 2SC3775-3-TB-E T 89.1/46.4
Q30 1530002241 S.TR 2SC3775-3-TB-E T 101.5/46.4
Q32 1590000660 S.TR DTC144TU T106 T 61.7/42.8
Q33 1590000430 S.TR DTC144EUA T106 T 65.6/41
Q35 1510000920 S.TR 2SA1577 T106 Q T 129.4/41.4
Q36 1590000430 S.TR DTC144EUA T106 T 132.9/42.3
Q37 1590000660 S.TR DTC144TU T106 T 68.2/39.3
D1 1710001081 DIO L308CCB
D3 1750000581 S.DIO 1SV307 (TPH3 F) T 14.8/40.7
D4 1750000581 S.DIO 1SV307 (TPH3 F) T 18/40.7
D11 1750000431 S.DIO HSB88WSTR-E T 58.5/6.2
D12 1790001330 S.ZEN MA8036-L (TX) B 113.7/7.4
D15 1790000980 S.DIO MA742 (TX) B 97/1.6
D21 1750000431 S.DIO HSB88WSTR-E T 59.5/26.3
D22 1790001330 S.ZEN MA8036-L (TX) B 122.8/34.8
D32 1720000811 S.VCP HVC358BTRF-E T 95/17.1
D33 1720000811 S.VCP HVC358BTRF-E T 94.3/15.7
D35 1720000661 S.VCP 1SV288 (TPH2 F) T 129.2/18.9
D37 1720000261 S.VCP 1SV214 (TPH2 F) T 88.8/29.5
D39 1720000261 S.VCP 1SV214 (TPH2 F) T 91.3/28.6
D40 1720000261 S.VCP 1SV214 (TPH2 F) T 91.3/30.4
D41 1790001621 S.DIO 1SV308 (TPL3 F) T 94.3/28.3
D42 1790000620 S.DIO MA77 (TX) T 68.4/36
D43 1790000620 S.DIO MA77 (TX) B 71.8/37
D44 1750000550 S.DIO 1SS355 TE-17 T 94.9/43
D46 1710001081 DIO L308CCB
D47 1790000691 S.DIO HSM88ASRTR-E T 61.7/49.6
D48 1790000691 S.DIO HSM88ASRTR-E T 61.7/46.2
D49 1730002320 S.ZEN MA8051-M (TX) T 74.9/46.3
D52 1790001250 S.DIO MA2S111-(TX)
FI1 2030000580 MLH FL-404 (30.15 MHz)
FI3 2020001270 CER CFWLB450KE2A-B0)
FI4 2030000350 MLH 21R15AB (FL-368)
FI5 2030000480 MLH 21R15AB (FL-399)
FI6 2020001840 CER ALFYM450F=K
X1 6070000191 S.DCR CDBKB450KCAY24-R0 T 108.1/12.5
X2 6070000191 S.DCR CDBKB450KCAY24-R0 T 113.8/45.3
X3 6050012120 S.XTL CR-804 (21.250 MHz) T 123.4/43.5
X4 6050012370 S.XTL CR-827 (15.3 MHz) T 124.6/21.1
L1 6110001600 COL LA-243
L2 6110001600 COL LA-243
L3 6110001600 COL LA-243
L4 6110001580 COL LA-238
L5 6200003550 S.COL MLF1608A 4R7K-T T 15.6/38.5
L6 6200003550 S.COL MLF1608A 4R7K-T T 18.8/38.5
L11 6190001591 COL #E526HNA-100312
L12 6190001591 COL #E526HNA-100312
L13 6190001591 COL #E526HNA-100312
L14 6190001591 COL #E526HNA-100312
