6 - 6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R257 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 69.4/33.9
R258 7030003270 S.RES ERJ3GEYJ 390 V (39) T 81.2/44.8
R259 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 80.6/46.7
R260 7030003390 S.RES ERJ3GEYJ 391 V (390) T 82.5/46
R262 7030003200 S.RES ERJ3GEYJ 100 V (10) T 94.8/46.5
R263 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 86.7/46
R264 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 86.7/43.3
R265 7030003320 S.RES ERJ3GEYJ 101 V (100) T 90.7/43.3
R267 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 96.1/45.2
R268 7030003310 S.RES ERJ3GEYJ 820 V (82) T 96.8/47.1
R271 7030003240 S.RES ERJ3GEYJ 220 V (22) T 107.9/47.1
R272 7030003240 S.RES ERJ3GEYJ 220 V (22) T 107.9/45.8
R273 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 100.9/43.3
R274 7030003310 S.RES ERJ3GEYJ 820 V (82) T 102.2/43.3
R275 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 56.5/50.3
R276 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 57.3/47.6
R277 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k) T 57.9/50.3
R278 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k) T 58.5/46.2
R282 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 64/44
R283 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k) T 67.6/43.8
R284 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 67.6/46.6
R285 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) T 68.9/43.8
R286 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 72.6/46.8
R287 7030003400 S.RES ERJ3GEYJ 471 V (470) T 77.9/42.5
R288 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 70.6/39.2
R290 7030003320 S.RES ERJ3GEYJ 101 V (100) T 78.6/46.1
R291 7030003400 S.RES ERJ3GEYJ 471 V (470) T 144.4/16.5
R292 7030003400 S.RES ERJ3GEYJ 471 V (470) T 144.4/18.5
R293 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 132.5/28.1
R295 7030003860 S.RES ERJ3GE JPW V T 132.5/23.4
R296 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 129.4/39.3
R297 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 130.8/43.5
R299 7410000950 S.ARY EXB-V8V 102JV T 123.3/26.7
R302 7510001661 S.TMR NTCG16 4LH 473JT T 127.6/23.1
R306 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 134.6/28.8
R308 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 135.6/30.2
R309 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 142.8/31.2
R310 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 135.6/31.5
R311 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 142.8/32.5
R312 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 135.6/32.8
R313 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 134.1/34.1
R314 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 142.8/33.9
R315 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 142.8/35.3
R316 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 132/35.8
R317 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 142.8/37.5
R318 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 134.4/37.8
R319 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 142.9/38.8
R320 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 134.4/39.1
R321 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 134.4/40.4
R322 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135.7/41.7
R323 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 142.8/41.4
R324 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 138.4/3.5
R325 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 137.2/6.2
R326 7030003860 S.RES ERJ3GE JPW V T 136.1/13.1
R327 7030003860 S.RES ERJ3GE JPW V T 143.9/14.6
R328 7030003860 S.RES ERJ3GE JPW V T 138.4/13.8
R329 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 145/9.7
R330 7030003620 S.RES ERJ3GEYJ 333 V (33 k) T 22.6/30.5
R331 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 21.3/30.5
R332 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 16/27.8
R333 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 21.9/28.4
R334 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 21.9/27.1
R335 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 21.4/20.6
R336 7030004050 S.RES ERJ3GEYJ 1R0 V (1) B 17.6/24.3
R337 7030003320 S.RES ERJ3GEYJ 101 V (100) T 16.7/25.5
R338 7030003320 S.RES ERJ3GEYJ 101 V (100) T 24.2/24.7
R341 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 63.1/40.7
R342 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 63.1/39.4
R343 7510001461 S.TMR NTCG16 3NH 471JT T 149.7/6.9
C1 4030011070 S.CER GRM31M2C2H5R0CY21L T 28.2/51.3
C3 4030011190 S.CER GRM31M2C2H270JV01L T 28.3/47.7
C5 4030011170 S.CER GRM31M2C2H180JV01L T 32/46.7
C6 4030017200 S.CER GRM31BR32J102KY01L T 35.6/45.1
C7 4030011210 S.CER GRM31M2C2H330JV01L T 40.6/43
C8 4030011190 S.CER GRM31M2C2H270JV01L T 40.6/38.6
C9 4030018350 S.CER GRM31A5C2J151JW01D T 31.5/29.4
C11 4030006860 S.CER C1608 JB 1H 102K-T T 14.8/34
C12 4030006860 S.CER C1608 JB 1H 102K-T T 16.4/40.7
C13 4030006860 S.CER C1608 JB 1H 102K-T T 18/34
C14 4030006860 S.CER C1608 JB 1H 102K-T T 19.6/40.7
C21 4030006860 S.CER C1608 JB 1H 102K-T T 14.8/31.2
C23 4030007070 S.CER C1608 CH 1H 330J-T T 6.6/30.4
C24 4030007040 S.CER C1608 CH 1H 180J-T B 11.5/31.9
C25 4030009530 S.CER C1608 CH 1H 030B-T B 11.5/30.3
C26 4030007170 S.CER C1608 CH 1H 221J-T T 8.1/28.8
C27 4030006850 S.CER C1608 JB 1H 471K-T T 10.7/26.2
C28 4030006860 S.CER C1608 JB 1H 102K-T T 9.9/22.7
C29 4030011600 S.CER C1608 JB 1E 104K-T T 9.9/24
C30 4030006850 S.CER C1608 JB 1H 471K-T T 5.7/26.8
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C32 4030011600 S.CER C1608 JB 1E 104K-T T 14.3/21.3
C33 4030009920 S.CER C1608 CH 1H 050B-T B 8/15.6
C34 4030009920 S.CER C1608 CH 1H 050B-T B 8/14
C35 4030006860 S.CER C1608 JB 1H 102K-T T 12.9/21.8
C36 4030009520 S.CER C1608 CH 1H 020B-T B 15.1/7.2
C37 4030009350 S.CER C1608 CH 1H 3R5B-T B 18.7/8
C38 4030006990 S.CER C1608 CH 1H 080D-T B 20.3/8
C39 4030009540 S.CER C1608 CH 1H 1R5B-T B 23.8/7.2
C40 4030009520 S.CER C1608 CH 1H 020B-T B 26.9/7.2
C41 4030009350 S.CER C1608 CH 1H 3R5B-T B 30.2/8
C42 4030006990 S.CER C1608 CH 1H 080D-T B 31.8/8
C43 4030009510 S.CER C1608 CH 1H 010B-T B 35.3/7.2
C44 4030009530 S.CER C1608 CH 1H 030B-T B 41.7/6.4
C45 4030007020 S.CER C1608 CH 1H 120J-T B 43.3/6.4
C47 4030007100 S.CER C1608 CH 1H 560J-T B 43.3/9.6
C48 4030009550 S.CER C1608 CH 1H 2R5B-T B 11.5/7.2
C49 4030009520 S.CER C1608 CH 1H 020B-T T 60.9/6.2
C52 4030006860 S.CER C1608 JB 1H 102K-T T 62.7/14.1
C53 4030007060 S.CER C1608 CH 1H 270J-T T 64.7/14.5
C54 4030007060 S.CER C1608 CH 1H 270J-T T 65.1/16.6
C55 4030006900 S.CER C1608 JB 1H 103K-T B 68/3.7
C56 4030006860 S.CER C1608 JB 1H 102K-T T 14.9/17.9
C57 4030006900 S.CER C1608 JB 1H 103K-T T 16.8/17.4
C59 4030006900 S.CER C1608 JB 1H 103K-T B 73.8/10.1
C60 4030006860 S.CER C1608 JB 1H 102K-T B 75.1/7.7
C61 4030018400 S.CER CM105 CH 330G 50AT B 74.4/4.8
C62 4030009540 S.CER C1608 CH 1H 1R5B-T B 74.4/6.4
C63 4030006900 S.CER C1608 JB 1H 103K-T T 72.5/12
C64 4030011770 S.CER C1608 CH 1H 060B-T B 89.9/2.6
C67 4030009520 S.CER C1608 CH 1H 020B-T B 89.9/5.8
C68 4030006900 S.CER C1608 JB 1H 103K-T B 106.8/4.2
C69 4030011600 S.CER C1608 JB 1E 104K-T T 109.1/5.3
C70 4030006860 S.CER C1608 JB 1H 102K-T B 109.5/11
C71 4030006860 S.CER C1608 JB 1H 102K-T B 109.5/14.2
C72 4030007120 S.CER C1608 CH 1H 820J-T T 109.1/8
C73 4030007090 S.CER C1608 CH 1H 470J-T T 75.9/38.3
C74 4030011600 S.CER C1608 JB 1E 104K-T T 77.8/37.5
C77 4550007520 S.TAN F931A106MAABMA T 104.2/3.1
C78 4030006900 S.CER C1608 JB 1H 103K-T B 117.1/6
C79 4030017490 S.CER C1608 JB 1A 105K-T B 113.9/4.4
C80 4030006900 S.CER C1608 JB 1H 103K-T T 112.5/14.3
C81 4030006860 S.CER C1608 JB 1H 102K-T B 117.1/7.3
C83 4030011600 S.CER C1608 JB 1E 104K-T T 118.3/10.4
C87 4030011280 S.CER C1608 CH 1H 271J-T B 115.3/12.2
C88 4030011280 S.CER C1608 CH 1H 271J-T B 119/10.5
C89 4030011600 S.CER C1608 JB 1E 104K-T T 132.1/14.7
C90 4030006860 S.CER C1608 JB 1H 102K-T B 104.6/5
C91 4030006900 S.CER C1608 JB 1H 103K-T B 100.7/6
C92 4030006900 S.CER C1608 JB 1H 103K-T B 104.6/9
C93 4030011810 S.CER C1608 JB 1A 224K-T T 107.7/5.3
C94 4030011810 S.CER C1608 JB 1A 224K-T T 150.3/9.7
C95 4030011600 S.CER C1608 JB 1E 104K-T T 148.4/11.7
C96 4030006860 S.CER C1608 JB 1H 102K-T B 99.9/2.2
C98 4550007520 S.TAN F931A106MAABMA T 156.9/35.3
C99 4030011600 S.CER C1608 JB 1E 104K-T T 155.4/37
C100 4030011600 S.CER C1608 JB 1E 104K-T T 144.9/43.9
C102 4030011600 S.CER C1608 JB 1E 104K-T T 146.8/32.7
C103 4030008850 S.CER C1608 JB 1H 123K-T T 149.4/29
C104 4030008900 S.CER C1608 JB 1H 333K-T T 150.7/32.9
C105 4030008900 S.CER C1608 JB 1H 333K-T T 149.4/32.9
C106 4030006850 S.CER C1608 JB 1H 471K-T T 151.5/29.5
C113 4030011600 S.CER C1608 JB 1E 104K-T T 151.1/19.4
C114 4030006850 S.CER C1608 JB 1H 471K-T B 154.5/22.8
C150 4030006860 S.CER C1608 JB 1H 102K-T T 61.6/31.5
C151 4030007060 S.CER C1608 CH 1H 270J-T T 65.4/32.1
C152 4030008560 S.CER C1608 CH 1H 300J-T T 65.4/33.4
C155 4030006900 S.CER C1608 JB 1H 103K-T B 68/28.4
C157 4030006900 S.CER C1608 JB 1H 103K-T B 75.7/28.7
C158 4030006860 S.CER C1608 JB 1H 102K-T B 77.9/26.9
C159 4030009530 S.CER C1608 CH 1H 030B-T B 75.6/25.6
C160 4030018400 S.CER CM105 CH 330G 50AT B 74.9/26.9
C161 4030006900 S.CER C1608 JB 1H 103K-T T 71.2/23.8
C164 4030009910 S.CER C1608 CH 1H 040B-T B 82.8/25
C165 4030009920 S.CER C1608 CH 1H 050B-T B 87.9/24.5
C166 4030006900 S.CER C1608 JB 1H 103K-T B 102.1/24.6
C167 4030011600 S.CER C1608 JB 1E 104K-T T 110.2/35.8
C168 4030006860 S.CER C1608 JB 1H 102K-T T 110/40.8
C169 4030006860 S.CER C1608 JB 1H 102K-T T 108.9/35.8
C170 4030007130 S.CER C1608 CH 1H 101J-T T 110.2/38.5
C171 4030007090 S.CER C1608 CH 1H 470J-T B 112.5/39.8
C172 4030011600 S.CER C1608 JB 1E 104K-T T 130.2/37.2
C175 4550007520 S.TAN F931A106MAABMA T 110.5/31.9
C176 4030006900 S.CER C1608 JB 1H 103K-T B 116.7/40.4
C177 4030017490 S.CER C1608 JB 1A 105K-T B 118.1/36.9
C178 4030006900 S.CER C1608 JB 1H 103K-T B 118/34.2
C179 4030006860 S.CER C1608 JB 1H 102K-T B 114.8/33.5
C182 4030011600 S.CER C1608 JB 1E 104K-T B 118.6/40.4
C183 4030007040 S.CER C1608 CH 1H 180J-T T 119.1/42.8
C183 4030007100 S.CER C1608 CH 1H 560J-T T 119.1/42.8
C184 4030007020 S.CER C1608 CH 1H 120J-T T 118.2/40.9
C186 4550007520 S.TAN F931A106MAABMA B 146/25
