Icom IC-M72 - Supplied Battery Charger

25
8
BATTERY CHARGING
New2001
8
■ Supplied battery charger
D BC-166 installation D Charging
q Connect the AC adapter as shown below.
w Insert the battery pack with/without the transceiver into the
charger.
• The charge indicator lights orange.
e Charge the battery pack approx. 11 hours, depending on
the remaining power condition.
• The charge indicator lights green when charging is complete.
NOTE: The battery charger, BC-166, has charging timer.
The timer stops the charging process after 14 hours
(ap-
prox.).
Transceiver
Battery
pack
AC
adapter
Turn the transceiv-
er power OFF dur-
ing charging.
Charger indicator
q
w
e
Supplied screws
Supplied screws
• To a desktop
• For added stability
• To a wall
Eyelet:
Use a rubber band to
secure the transceiv-
er, if desired.
