Icom IC-V8 Service Manual

S.=Surface mount
C361 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C363 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C364 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C365 4030009560 S.CERAMIC C1608 CH 1H R75B-T-A
C367 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C368 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C369 4030008900 S.CERAMIC C1608 JB 1C 333K-T-A
C370 4030009970 S.CERAMIC C1608 JB 1H 182K-T-A
C372 4030008880 S.CERAMIC C1608 JB 1C 223K-T-A
C373 4030009880 S.CERAMIC C1608 JB 1H 682K-T-A
C374 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
C375 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C376 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C377 4550006350 S.TANTALUM TEMSVB2 1A 226M-8L
C378 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C379 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C380 4510005430
S.ELECTROLYTIC ECEV0JA220SR
C381 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C385 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C386 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C387 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C388 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C389 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C390 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
C391 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C392 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C393 4550006760 S.TANTALUM TEMSVB2 1A 336M-8R
C394 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C395 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C396 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C397 4030006950 S.CERAMIC C1608 CH 1H 040C-T-A
C398 4550005980 S.TANTALUM TEMSVA 1A 475M-8L
C399 4030008650 S.CERAMIC C1608 JB 1H 332K-T-A
C400 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
J2 6450001680 CONNECTOR HSJ1122-010010
J3 6450001690 CONNECTOR HSJ1456-01-220
J5 6510018430 S.CONNECTOR AXN330C038P
J6 6510021900 S.CONNECTOR BM02B-ASRS-TF
DS1 5030002000 LCD TTR5515 UPFDHW
DS2 5010000160 S.LED LNJ310M6URA
DS3 5010000160 S.LED LNJ310M6URA
MC1 7700002160 MICROPHON KUC3523-040245
S1 2230001070 S.SWITCH JPM1990-2711R
S2 2230001070 S.SWITCH JPM1990-2711R
S3 2230001070 S.SWITCH JPM1990-2711R
S801 7600000210 ENCODER TP70N00E20-15F-1903
W7 7030003860 S.JUMPER ERJ3GE JPW V
W8 7030003860 S.JUMPER ERJ3GE JPW V
W9 7030003860 S.JUMPER ERJ3GE JPW V
W11 7030003860 S.JUMPER ERJ3GE JPW V
W12 7030003860 S.JUMPER ERJ3GE JPW V
W13 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910053802 PCB B 5649B
EP2 8930051310 LCD CONTACT SRCN-2251-SP-N-W
EP3 6910012350 S.BEAD MMZ1608Y 102BT
EP4 6910012350 S.BEAD MMZ1608Y 102BT
EP5 6910012350 S.BEAD MMZ1608Y 102BT
6 - 4
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]

Icom IC-V8 Specifications

General

Frequency Range	136-174 MHz
Power Output	5.5 W
Mode	FM
Receiver Sensitivity	0.16 μV (12dB SINAD)
Channel Spacing	12.5/25 kHz
Voltage	7.2 V DC
