Icom IC-V8 Service Manual
5
of 1
of 1 rating
31 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
3 - 2
3-2 OPTIONAL
UNIT INST
ALLA
TIONS
1
Remove the option cover.
2
Remove the bottom protective paper of spoge.
3
Connect the UT-108 optional unit to J5.
4
Replace the option cover to the chassis-hole.
SPONGE
Parts name
: 1556 sponge
Order No.
: 8930013545
Option cover
Option unit
J5
6
8
