⦁ Repeat Reading Functions: Allow the reader to continuously reread a card that is kept within range. The
reader can also be set to silently reread the card. This option can be used with the PRX-TSEC-XCDH card
holder cover.
⦁ Low Frequency Prox Options: Enable/Disable reading of various low frequency formats.
⦁ Clone Card Options: Enable/Disable clone card reading and clone card destroy.
⦁ Card Serial Number Reading: Enable/Disable reading of CSN for MIFARE, DESFire, and other NFC cards.
⦁ Wiegand Site Code: The site code to send when using Keypad Formats that can send a site code.
Advanced Settings
The following settings include more advanced configurations that affect critical reader operation.
Important: It is possible to prevent a reader from reading cards, INCLUDINGCONFIGURATIONCARDS, using
some of these settings. Only use advanced configuration settings if you have been instructed to do so by ICT
Technical Support. If you are not certain please get in touch with the Technical Support team.
⦁ Bluetooth Power Output: Manually set the power that the BLE module outputs, effectively controlling the
Bluetooth reading range for the reader.
Changing this setting can cause the Bluetooth on a reader to stop working.
⦁ Custom RS485 Format: Specifies the RS-485 format to use if the reader has been set to Custom Serial Output
Mode.
⦁ Custom Card Format: Allows the entry of a custom format string which describes how to interpret data from
the card being read.
Changing this setting can stop a reader from reading cards. Consult ICT Support before using this setting.
⦁ Encryption Key Slot: Used to load custom Encryption Keys onto the reader. Must be used in conjunction with
Credential Type and Credential Format Link settings.
⦁ Credential Type: Used to configure the details of reading of different types of credentials.
Changing this setting can stop a reader from reading cards. Consult ICT Support before using this setting.
⦁ Credential Format Link: Used to link Credential Types, Custom Card Formats, and Encryption Keys.
Changing this setting can stop a reader from reading cards. Consult ICT Support before using this setting.
Programming a Card Reader
Once the required Config Card is available, it can be used to easily program readers.
ICT card readers can only be programmed within 2 minutes of startup. In order to program the reader you will
need to disconnect power and complete programming within 2 minutes of powering up.
To program a Card Reader using a Config Card
1. Power cycle the reader to be programmed. The configuration must be completed in the next 2 minutes.
2. To apply the new configuration to the reader, place and hold the config card close to the reader.
3. When programming is successful, the reader will beep 4 times quickly and then restart.
If the reader beeps 3 times slowly the configuration has failed. Wait for the reader to restart and try again.
ICT Card Reader | Configuration Guide 31
