ICT Protege - 125 kHz Reading Modes; Wiegand Output Formats

125kHz Programming
125kHz Reading Mode
Reading mode determines how the data on the 125kHz card is processed by the reader.
The following options are available by badging a programming card once to enter Address 1.
Function
125kHz
Setting
Description
1 All 125KHz cards will be read (no filtering)
ICT 2 Can only read ICT programmed cards
POSTECH 3
Can only read POSTECH programmed cards. Selecting this option disables the
programming card.
HID 4
Can only read HID programmed cards. Selecting this option disables the
programming card.
ICT & HID 5 Can only read ICT and HID programmed cards
ICT & POSTECH 6 Can only read ICT and POSTECH programmed cards
POSTECH & HID 7
Can only read POSTECH and HID programmed cards. Selecting this option
disables the programming card.
Wiegand Output Format
When the Output Mode of the reader is set to Wiegand, the interface programming configures how the reader
sends information to the connected system.
The following options are available by badging the programming card twice to enter Address 2.
Setting
125kHz
Setting
Description
Auto
1
When a card is badged, the number of bits sent is determined by the
information encoded on the card.
26 Bit Wiegand 2
Standard 26 Bit Wiegand data sent on the D0 and D1 data lines. Truncation
of site/facility codes will occur for any card or tag programmed with a site
code above 255.
27 Bit Tecom Wiegand 3
Tecom formatted 27 Bit Wiegand sent on the D0 and D1 data lines.
Truncation of site/facility codes will occur for any card or tag programmed
with a site code above 2048.
32 Bit Wiegand 4
Standard 32 Bit Wiegand data sent on the D0 and D1 data lines. No
truncation will typically occur; however, it is recommended that you use
industry standard 34 Bit. 32 Bit Wiegand has no parity or other error
checking.
34 Bit Wiegand 5 Standard 34 Bit Wiegand data sent on the D0 and D1 data lines.
66 Bit Wiegand 6 Standard 66 Bit Wiegand data sent on the D0 and D1 data lines.
37 Bit Wiegand 7 Standard 37 Bit Wiegand data sent on the D0 and D1 data lines.
64 Bit Wiegand 8 Standard 64 Bit Wiegand data sent on the D0 and D1 data lines.
Kantech KSF 9 Kantech formatted 26 Bit Wiegand sent on the D0 and D1 data lines.
ICT Card Reader | Configuration Guide 34
