Programming Example
Programming the Interface to output 26 Bit Wiegand:
1. Present the programming card to the reader once to initiate Programming Mode. The card reader will respond
by beeping twice to indicate that Programming Mode has been entered.
2. Once Programming Mode has been entered, present the programming card twice to enter Address 2, the
Programming Option for Wiegand Output Format. The card reader will respond by beeping twice to indicate
that it has entered the Wiegand Output Format menu.
3. Next, present the programming card twice, corresponding with the 125kHz Setting (2) for 26 Bit Wiegand.
Wait for the reader to beep twice, indicating the data has been programmed correctly.
4. Continue programming additional settings, or leave the programming interface to time out.
Programming Option Addresses
Address Programming Options
1 125kHz Reading Mode
2 Wiegand Output Format
3 LED Function
4 Intelligent Tamper Mode
5 Enable ASK (EM) Cards
6 PIN Data Interface
7 PSK Unscramble
8 PSK Enable
12 Factory Default
ICT Card Reader | Configuration Guide 33
