LED Function
The LED function allows the configuration of dual or single line LED operation. The default is single LED mode, Blue
On.
The following options are available by badging the programming card three times to enter Address 3.
Setting
125kHz
Setting
Description
Dual 1
Grounding the orange wire will enable the green LED. Grounding the brown wire will
enable the blue LED.
Blue On 2
The blue LED is on by default. Grounding the brown wire turns off the blue LED and
turns on the green LED.
Green On 3
The green LED is on by default. Grounding the brown wire turns off the green LED
and turns on the blue LED.
Intelligent Tamper Mode
Enabling the intelligent reader tamper mode will force the card reader to check in to the device it is connected to
every 30 seconds.
The following options are available by badging the programming card four times to enter Address 4.
Function Setting
Disabled 1
Enabled 2
Only enable Intelligent Reader Tamper Mode if the access control system or reader interface supports intelligent
tamper operation.
Enable ASK (EM) Cards
This enables the card reader to read ASK (EM) formatted cards. By default, this feature is enabled only if the
PSK/EM hardware is fitted.
The following options are available by badging the programming card five times to enter Address 5.
Function Setting
Disabled 1
Enabled 2
PIN Data Interface
The PIN data interface format defines how the PIN data is sent using the D0 and D1 data interface.
The following options are available by badging the programming card six times to enter Address 6.
Setting Function Max PIN (when using a reader module)
1 ARK-501 99999999
2 26 Bit Wiegand Format 65535
3 4 Bit 99999999
4 4 Bit with Parity 99999999
