IDEAL TILT-A WAY HYJG 1

Concrete Embedment Block top at grade line or below size to suit conditions
Barrier Post flush with stanchion.
Barrier Main Tube 3 3/4" Clearance to grade-line
Grade Line
BARRIER END STANCHION
N/A
N/A
N/A
PART NO.
IDEAL MANUFACTURING INC.
6
REF NO.
1
5
4
3
2
FGO172
Photo Eye
95
DESCRIPTION
Stanchion Unit
Date: 3-25-2016 HYJG-254
2
REQ NO
1
N/A
PEO454
N/A
N/A
1
REQ NO
4
Surface Mount Stanchion Unit
DESCRIPTION
3/4" x 6" Exposed Bolts
5/16" Hex Nut
FGO407
2
3
4
5
1
REF NO.
NA7
6
PART NO.
N/A
PEO454
FGO406
SURFACE MOUNT STANCHION
5/16" x 1" Bolt
Photo Eye ( 2 on operator)
Photo Eye Mount
5/16" Lock Washer
2
2
4
4
4
BOTTOM OF BARRIER
TO
TOP OF CONCRETE
BOTTOM OF BARRIER
TO
TOP OF BASE
