TILT-A-WAY
HYDRAULIC VERTICAL PIVOT GATE
HYJG 1 HYDRAULIC UNIT
REF NO.
PART NO.
DESCRIPTION QTY
1 100125A
100137
100136A
1 HP, 110/220 VAC 1PH, TEFC, MOTOR
1 HP, 24 VDC, TEFC, MOTOR
1 HP, 240/480 VAC 3 PH, TEFC, MOTOR
1
2 100145 3/8" TUBING RETURN 1
3 TWO512 GEAR PUMP 1
4 TWO513 IN TANK FILTER HOUSING 1
5 TWO514 7 MICRON NOMINAL CELLULOUSE FILTER 1
6 100139 MANIFOLD 1
7 100121 DIRECTIONAL VALVE 1
8 100142 CUSTOM RESERVOIR 1
9 100143 SIGHT GLASS 1
10 TWO519 BREATHER FILLER CAP 1
11 TWO520
TWO462
240 VAC 1PH HEATER W/ THERMOSTAT
120 VAC HEATER W/ THERMOSTAT DC UNIT
1
12 TWO523 BY PASS VALVE 2
13 TWO522 PRESSURE RELIEF VALVE 1
14 TWO526 #12 MORB X #16 HOSE BARB ADAPTER 1
15 TWO528 #6 MORB X #6 MJIC ADAPTER 3
16 TWO529 #8 MORB X #6 MJIC 90 DEG. ADAPTER 1
17 TWO530 #10 MORB X #6 MJIC 90 DEG. ADAPTER 1
18 100144 3/8" TUBING PRESSURE 1
19 N/A 10-24 X 3 SOCKET HEAD CAP SCREW 4
20 N/A 1/4-20 X ½ FLANGE BOLT 3
21 N/A 1/4-20 X 1 SOCKET HEAD CAP SCREW 2
22 N/A ¼-20 NYLOCK HEX NUT 2
23 N/A 3/8 LOCK WASHER 12
24 N/A 3/8-16 X 1 HEX BOLT 10
25 N/A 3/8-16 X 1 1/4 HEX BOLT 2
26 N/A 5/16 LOCK WASHER 4
27 N/A 5/16 X 3/4 HEX BOLT 4
28 100138 BYPASS VALVE BODY 1
29 100123 VALVE DRIVER 2
30 TWO579 #6 MORB X #6 MJIC 90 DEG. ADAPTER 1
31 100140 GASKET 1
32
