IDEAL TILT-A WAY HYJG 1 User Manual

HYJG-202
6
IDEAL MANUFACTURING INC.
6-10-2015
Cord to Interface Board
TILT-A-WAY
HYJG 1
LOGIC CONTROL BOARD
Programmable Loop Detector sockets
12 Volt DC Power
Maximum Current Draw
1 amp Total (not fused)
Optional Radio
Receiver
UL 325 Entrapement Reset Button
Wires To Motor
Control Board
24 Volt DC Power In
24 Volt DC
Power Out 5 amp
Fuse Protected
Entrapment dry
contact (NO)
Prewarn
dry contacts
(NO and NC)
Aux Relay #1
dry contact (NO)
Controller
Ground
Aux Relay #2
dry contact (NO)
Aux Relay #3
dry contacts
(NO and NC)
On Board Push
Button Station
Open Input
Close Input
Stop Input
Single Input
Aux Timer Input
Timer Hole Input
Rev Open Input
Timer Set Input
Aux #1 Input
Aux #2 Input
Leaf 1 Closing Safety
Leaf 1 Opening Safety
Leaf 2 Closing Safety
Leaf 2 Opening Safety
5amp Fuse
Not Used
