7
TILT-A-WAY
HYJG 1 MOTOR CONTROL BOARD
Wires From
Logic Board
Wires To
Potentiometer
Wires To Limit
Switch's (NC)
Wires To Motor
Contactor
Power In From
Logic Board
2 amp Fuse
HYJG-203
IDEAL MANUFACTURING INC.
6-10-2015
Wires To Close
Solenoid Valve
WiresTo Open
Solenoid Valve
HYDRAULIC
IDEAL MFG., INC.
