IDEAL TILT-A WAY HYJG 1 User Manual

IDEAL MANUFACTURING INC.
63
HYJG-233
Conduit Routed from Barrier Pedestal.
Concrete Support Pier 15" X 15" X 24" Deep
Dual Height Pedestal 72" in Height
1" in Diameter Electrical Conduit with 2 1/2" projection above Concrete.
PART NO.
5
8
6
7
N/A
N/A
NA
N/A
REF NO.
1
4
3
2
N/A
1/2" Hex Nut
Remote Control Station of Choice
1/2" Lock Washer
(Included are bolts, nuts, keys and plate.
DESCRIPTION
Single Height Pedestal
4
4
4
4
REQ NO
1
1
1
1
N/A
N/A
N/A
1/2" x 8" Expansion Bolt
TILT-A-WAY HYJG 1
REMOTE CONTROL STATION PEDESTAL AND GATELOCK
3/24/2016
