IDEAL TILT-A WAY HYJG 1 User Manual

PEO246
PEO410
2
REQ NO
4
Opening Edge Holding Track
DESCRIPTION
1/2" Strain Relief Fitting (not shown)
PEO653
2
3
4
5
1
REF NO.
PART NO.
PEO654
PEO651-A
PEO652-A Length
Open safety, with resistor
PEO237
Junction Box Cover (not shown)
2
1
1
1
1
Junction Box
6
N/A
18/5 S O Cord AS REQ
Close safety, with resistor
Closing Edge Holding Track (Length is required)
TILT-A-WAY HYJG 1
MONITORED
REVERSING EDGE INSTALLATION
IDEAL MANUFACTURING INC.
64
HYJG-23410/1/2018
NOTE: FOR THE MONITORED EDGE
TO FUNCTION PROPERLY IT MUST BE ENABLED.
THIS FUNCTION IS IN THE TIMING AND OPTIONS MENU.
SAFETY RESPONSES SUB MENU.
MONITORED OBTRUCTION EDGE (DISABLED / ENABLED)
REVERSING EDGE ON SLAVE GATE
