IDEAL TILT-A WAY HYJG 1

1 1
2 2
3 3
4 4
A A B B C C D D
SHEET 1 OF 1
DRAWN CHECKED QA MFG APPROVED T Henry
12/4/2015 3/24/2016
DWG NO HYJG-240
TITLE HYJG 1 COVERS
SIZE
C
SCALE
Ideal Mfg., Inc.
REV
2011 Harnish Blvd.
Billings MT 59101
Tel. (406) 656-4360
PARTS LIST
DESCRIPTIONQTYPART NUMBERITEM
OUTER GUARD ALUMINUM AMPLIMESH1FGO1751 LEFT INNER GUARD FOR RIGHT HAND GATE
1
FGO4042
LEFT INNER GUARD FOR LEFT HAND GATE1FGO404A3 RIGHT INNER GUARD FOR RIGHT HAND GATE1FGO4054 RIGHT INNER GUARD FOR LEFT HAND GATE1FGO405A5 TOP COVER DOOR SIDE
1
FGO6736
TOP COVER PANNEL SIDE1FGO6747 REAR PANNEL FOR GATE 8' AND UNDER1FGO6769 REAR PANNEL FOR GATE 11' AND OVER
2FGO67710
11' GUARD
1
FGO678
11
12' GUARD1FGO67912 ACCESS DOOR3G0011913 T HANDLE LATCH3PEO96014 SIDE PANEL3FGO675A16
1
7
16
5
3
2
4
13
14
14
13
13
14
6
9 10
11
12
72
HYJG 1 RIGHT HAND OPERATOR
16
16
