IDEAL TILT-A WAY HYJG 1

IDEAL MANUFACTURING INC.
78
TILT-A-WAY
HYDRAULIC VERTICAL PIVOT GATE
BARRIER UNIT
HYJG 1
HYJG-248
1
REQ NO
PART NO.
DESCRIPTION
Serial # decal is located on the front of the elctrical enclosure.
Barrier assemblies are manufactured from steel or aluminum
ID1066
2
4
material and in varied lengths and heights.
When contacting manufacturer regarding a TILT-A-Way gate,
always provide complete serial number.
3/16" x 2 1/2 Stainless Steel Cotter Pin - 3 per inside tube
ID1063
ID10643
5/16 x 4" Eye Bolts (3 per end)
6
Wire Crimp
6
5
7
N/A
3/8" x 2 1/4" Hex Bolt for Aluminum Brace or
3/8" x 2" Hex Bolt for Steel Brace
3/8" Lock Washer
3/8" Hex Nut
6
N/A
N/A
N/A
5/16" Hex Nut
6
6
6
6
REF NO.
DATE: 3-24-2016
