TILT-A-WAY HYDRAULIC VERTICAL PIVOT GATE
OPERATOR FIELD INSTALLATION
DRAWING # HYJG-241 PAGE 67
HYJG 1
REF. NO. DESCRIPTION
Note: If gate does not operate on first try, but hydraulic pump runs
switch 2 power lines to reverse pump rotation.
1. Control pedestal HYJG
2. Concrete support slab Minimum dimensions 11’0” long x 4’0” wide x 1’6” thick.
To be placed on firm soil or compacted fill, reinforced with #4 rebar each way; and cement piling dug to frost
line by purchaser
NOTE: Will withstand and estimated 100 MPH wind in most soil conditions.
3. Electrical conduit area. Stub in electrical supply, 20 Amp service.
4. Four anchor bolts ¾” diameter X 12” with 2” projection.
5. Two base plates, welded to pedestal.
____________________________________________________________________________________________
TILT-A-WAY
HYDRAULIC OPERATOR INSTALLATION PROCEDURE FOR GATE THAT IS
SHIPPED UNASSEMBLED
1. Remove all materials used for protection during shipment.
2. Place pedestal on concrete pad. Align and level pedestal, drill four holes minimum 10” deep. Epoxy ¾” x 12
studs in holes. Follow epoxy manufacturers instructions.
3. Open rear access door to expose spring tension adjustment screws.
4. Find two fluid bypass valves, place in open position.
5. Back off spring tension screws to provide slack in tension cables. (1 5/8” socket needed)
6. Rotate barrier carriage to down position. Remove pivot shaft with attached components. Install barrier and
secure to vertical carriage post with five bolts and one bolt at outer end of carriage horizontal channel.
7. Place plastic rub washer over pivot shaft collar on carriage. Align cylinder rod end bearing with collar and
insert pivot shaft from far side. Secure with flat washer, lock washer and bolt.
8. Tighten spring tension screws while inspecting cables for proper wrap around balance sheaves. When slide
members have reached marks indicated on tracks. Proper balance tension will have been achieved. If at a later
date minor adjustment should be required, refer to balance system adjusting section.
9. Perform required electrical connections in accordance with diagrams shown in this manual.
10. Position fluid bypass valves to closed setting, close and secure access door.
11. If gate fails to function properly, contact manufacturer’s representative.
TILT-A-WAY
HYDRAULIC OPERATOR INSTALLATION PROCEDURE FOR GATE THAT IS
SHIPPED ASSEMBLED
1. Remove all materials used for protection during shipment.
2. Place operator and barrier on concrete pad. Align and level pedestal, drill four holes minimum 10” deep. Epoxy
¾” x 12 studs in holes. Follow epoxy manufacturers instructions.
3. Perform required electrical connections in accordance with diagrams shown in this manual.
4. Position fluid bypass valves to closed setting, close and secure access door.
5. If gate fails to function properly, contact manufacturer’s representative.
