3 – Switch on the OS310.
4 – At the end of the start-up messages from the Main Menu, select the “SERVICE Menu”.
5 – From the Service Menu, select the “DIAGNOSTIC menu”.
6 - From the Diagnostic Menu, select the “DISI”, diagnostic serial interface.
7 - Select the AUX1.
Afterwards, any character typed transmitted by the PC, is sent to the interfaced Single/Three-
Channel Fluorimeter through the selected serial communication port.
8 – Wait few seconds after the selection; in the meantime, you should see that on the ITERM window
appears the real-time measurements from the fluorimeter.
9 - Close the ITERM communication port using the “Port->Close” command.
10 – Leave the ITERM program running and start the interface software.
11 – Run the CHELSEA calibration program.
Note
To interrupt the diagnostic communication with the Single/Three-Channel Fluorimeter after the ITERM
communication port is re-opened, type CTRL-X on the keyboard..
The OCEAN SEVEN 310 uses a pre-defined not modifiable calibration coefficients:
Offset = 0.0 Slope = 1.0
