Firing bottle time step (MAX 600s)
The operator can select the time step between the firing of two consecutive bottles.
Note
The probe warm-up time-out must be increased from the standard 5 seconds to the more appropriate 30 seconds.
This quite long time-out is needed to cover the home positioning procedure taken by the Rosette once it awakes. In
fact, during the home positioning procedure, the Rosette does not answer the probe bottle firing request.
E.4 CONFIGURING THE ROSETTE
External equipment interfaced by the probe through digital, analogue or serial interface I/O can be
configured by means of the CNES command available under the Configuration Menu.
OCEAN SEVEN 310 - ID:0000000 {USR}(1.1_00 06/17)Oct 01 13:06:15.13 2016
--- Auxiliary setup ---
Aux.#1,select:(0)None,(1)Trilux,(2)Wetlab ECO
Aux.#1:0
Aux.#2-Rosette:(0)No,(1)GO1018,(2)SBE32c,(3)MISS
Aux.#2:1
After selecting the Rosette type, the following question must be answered depending on the chosen
Rosette type:
Number of bottles [1..24]
Enter the number of positions of your Rosette:
Home positioning timeout (s):120
Time spent waiting the rosette home positioning
Delay between commands (ms):2000
Time between consecutive rosette commands
ComPort:(2)Aux#1,(3)Aux#3,(4)Rosette
Com. [2..4]:4
Speed(BPS):(0)300,(1)600,(2)1k2,(3)2k4,(4)4k8,(5)7k2,(6)9k6
Baud Rate :0
Data bit:(0)7 bit, (1)8 bit
Data bit :1
Parity:(0)None,(1)Even,(2)Odd
Parity type:0
Stop bit:(0)1 bit, (1)2 bit
Stop bit :0
Flow Control:(0)None,(1)CTS/RTS,(2)DelayTx
Flow cnt :0
The communication port parameters are automatically proposed by the CTD accordingly with the
selected rosette. Do not change it!
